Filter Systems & Accessories
17-315
17-300
17-305
16-150
DIATOMACEOUS EARTH
FILTER SYSTEMS
MER-MADE VACUUM D.E. FILTER —
Commercial vacuum D.E. filter system takes
up to 1⁄4 of the space required for sand filters of
the same capacity. Vacuum D.E. systems are
easy to install, take less water to backwash,
and provide the highest water quality of
any system. Filter leaves are made of highimpact polystyrene and covered with woven
polypropylene fabric. Costs for filter system
are lower than other systems on the market.
Each system is custom designed based on
the gallonage of the pool. Stainless steel leaf
clamps, hold down bars, manifold support
clamps, and filter leaves are provided to install
in field fabricated concrete, fiberglass, or metal
filter tanks. Bottom outlet style listed, also
available in vertical edge outlet style. Contact
us to review your pool requirements and to
properly design your system.
Item
Grid Size
16-140
16-145
16-150
16-155
16-160
24" x 45"
30" x 36"
38" x 48"
30" x 60"
48" x 60"
Grid Sq. Ft.
Filter Area
15
15
25
25
40
MER-MADE FILTER ACCESSORIES — Can
be purchased as parts or as components to
the filter systems listed above.
16-165 Fiberglass D.E. filter tank
16-175 Leaf clamp assembly
16-180 Manifold support clamp
16-185 Rubber hold-down strip
16-190 Leaf gaskets
16-195 Felt collars
PENTAIR QUAD DE FILTERS — DE filter uses
four removable DE cartridges for greater dirt
trapping capacity. FRP filter tank for long life.
Backwash valve ordered separately. NSF Listed.
Item
Model
17-200 DE 60
17-205 DE 80
17-210 DE 100
Sq. Ft.
Tank
Tank
Filter
Port
Diameter
Area
Size
60
80
100
21.5"
21.5"
21.5"
2"
2"
2"
17-310
SPECIALTY VALVES
17-325
PENTAIR FULLFLO XF VALVES — Available
in 2-Way, 3-Way, and diverter styles. These
valves are ideal for diverting, shutoff, or mixing
applications. PTFE coated diverter seal requires
no lubrication. Can be operated by hand or
used with motorized valve actuator. Chemical
resistant CPVC material with 21/2"/3" connection.
17-300 3-Way Diverter valve
17-305 3-Way Solar valve, with drain down
17-310 2-Way Diverter valve
17-315 90 degree 2-Way valve
17-320 Motorized valve actuator, 90 degree
17-321 Motorized valve actuator, 120 degree
17-322 Motorized valve actuator, 180 degree
17-325 Straight body check valve
17-330 90 degree body check valve
17-335 Check valve rebuild kit
CARTRIDGE FILTERS
PENTAIR CLEAN & CLEAR FILTERS —
Durable FRP tank with union connections and
coreless cartridge for easy cleaning. 2" tank
ports with 1" drain and wash out opening. 151/2"
diameter tank, for tight installations. NSF Listed.
Item
Model
Number
17-250
17-255
17-260
17-265
17-270
CC 50
CC 75
CC 100
CC 150
CC 200
Sq. Ft.
Tank
Filter
Diameter
Area
50
75
100
150
200
151⁄2"
151⁄2"
151⁄2"
151⁄2"
151⁄2"
Tank
Port
Size
2"
2"
2"
2"
2"
17-175
BACKWASH VALVES
17-170
STA-RITE BACKWASH VALVES
17-170 2" ABS Unitrol valve, D.E. / Sand filters
17-175 2" Multiport Rotary valve, D.E./Sand filters
17-176 2" Multiport Rotary valve, Sys 3 D.E.
17-165
SEPARATION TANKS
16-175
16-180
40
STA-RITE D.E. SEPARATION TANK — For
efficient removal of spent D.E. and debris
from backwash water. Allows closed loop
system which returns backwash water to pool.
Eliminates D.E. disposal problems by trapping
material. Constructed of fiberglass reinforced
thermo-plastic. 2" NPT inlet and 1 1/2" NPT
outlet. For D.E. filter tanks up to 60 sq. ft.
17-165 D.E. Separation Tank
17-166 Replacement Separation Tank Bag
17-185
17-180
PENTAIR BACKWASH VALVES
17-180 2" PVC slide valve, D.E. / Sand filters
17-185 2" Multiport valve, D.E. filters
17-190 2" Multiport valve, D.E. / Sand filters
17-191 2" Hi Flow valve, D.E. / Sand filters
17-192 2" Hi Flow valve, D.E. filters
17-083 2" adapter kit, threaded (2 required)
www.lincolnaquatics.com
