Safety Equipment
49-010
49-005
WALL MOUNT EYE/FACE/BODY SPRAY
HEAD — Allows user the ability to wash all
parts of the face and body. Easy-to-use spray
unit features a chrome plated squeeze lever
for one-handed operation. Single spray head
has automatic pop-off dust cover. Vacuum
breaker is required on all hand held eye/face/
body spray units per local code, not included.
Includes: wall bracket, 12' recoil hose and
universal sign.
49-010
49-015
49-020
SELF-CONTAINED EYEWASH — Designed
for first aid in locations without accessible
plumbing. 16 gallon gravity-operated portable
polyethylene eyewash station. Pull tray down for
over 15 minutes of full flow at .4 GPM. Includes:
wall mounting bracket. Bacteriostatic additive
permits storage of water for up to 6 months
without growth of bacteria.
49-015 Self-Contained Eyewash
49-020 Bacteriostatic additive, 5 oz.
SHOWER & EYEWASH
STATIONS
SHOWER & EYEWASH STATION — Offers
immediate first aid. Full body drench shower
with choice of stainless steel or ABS plastic
bowl. Easily activated by push flag or
triangular pull handle. Stainless steel eyewash
and ABS plastic eyewash offer optional foot
treadle, and is ordered separately. Epoxy
coating adds an additional layer of protection
on all galvanized metal surfaces. Meets ANSI
and OSHA requirements.
Description
Standard
Stainless Steel
ABS Plastic
49-005
49-006
Epoxy
Coating
SHOWER AND EYEWASH PARTS
49-001 Eyewash head assembly
49-002 Dust cover
49-003 Shower head
49-004 Pull handle
49-007 Optional foot treadle
49-012
49-014
49-026
49-058
49-059
WALL WASH STATIONS
HAND-HELD WALL STATIONS —
49-017
PORTABLE EYEWASH TANK — Stainless
steel pressurized eyewash tank with drench
hose. Built-in carrying handles with flow
control spray head assemblies for steady
waterflow. Portable heated units maintain water
temperature at an average of 75°.
Eyewash Style
49-009
EYEWASH STATIONS
WALL MOUNT EYEWASH WITH BOWL —
Wall mount station with eye and face wash
head assembly. Provides superior spray to
the vulnerable nasal cavity when needed.
Features ABS plastic 11” receptor. Includes:
mesh in-line strainer to collect line debris, wall
bracket and universal sign.
49-009
TOLL FREE (800) 223-5450
Eyewash only
Eyewash with
drench hose
Heated Eyewash
Cart
Provides
immediate flushing until the injured person
can be helped to a primary emergency
device. Highly visible and readily available
for emergency flushing and decontamination.
Station includes: Eyesaline ® , sterile and
buffered saline solution which last 36 months
from manufacturing date.
49-026 Single Wall Wash Station, 32 oz.
49-024 Dual Wall Wash Station, 2 x 32 oz.
49-027 Repl. Saline solution, 32 oz.
5
10
15
Gallon Gallon Gallon
49-011 49-012 49-013
49-014 49-016 49-017
49-018 49-019 49-021
49-022 49-022 49-022
NOTE: Eyewash only units do not meet the
full 15-minute flushing requirements and
are intended for use as first aid treatment
prior to reaching an approved shower and
eyewash station.
49-024
109
