EXTREME HSS-G
EXTREME HSS-G
Metal Iron Stainless Steel Nickel Bronze
SKU Images
Diameter
Specification Length
Working length
DT5535-QZ 1 mm 34 mm 12 mm 10 DT5536-QZ 1.5 mm 60 mm 18 mm 10 DT5537-QZ 2 mm 49 mm 33 mm 10 DT5538-QZ 2.5 mm 57 mm 30 mm 10 DT5539-QZ 3 mm 61 mm 33 mm 10 DT5541-QZ 3.3 mm 65 mm 36 mm 10 DT5542-QZ 3.5 mm 70 mm 39 mm 10 DT5543-QZ
Pillot Point
4 mm 75 mm 43 mm 10 DT5544-QZ 4.2 mm 75 mm 43 mm 10 DT5545-QZ 4.5 mm 80 mm 46 mm 10 DT5546-QZ 4.8 mm 86 mm 46 mm 10 DT5547-QZ 5 mm 86 mm 46 mm 10 DT5548-QZ 5.5 mm 93 mm 57 mm 10 DT5549-QZ 6 mm 93 mm 57 mm 10
DT5550-QZ 6.5 mm 101 mm 58 mm 10 DT5551-QZ 7 mm 109 mm 66 mm 10 DT5552-QZ 7.5 mm 109 mm 66 mm 10 DT5553-QZ 8 mm 117 mm 72 mm 10 DT5554-QZ 8.5 mm 117 mm 72 mm 10 DT5555-QZ 9 mm 125 mm 78 mm 10 DT5556-QZ 9.5 mm 125 mm 78 mm 10
DT5557-QZ 10 mm 133 mm 84 mm 10 DT5558-QZ 10.5 mm 133 mm 84 mm 10 DT5559-QZ 11 mm 142 mm 91 mm 10 DT5560-QZ 11.5 mm 142 mm 91 mm 10 DT5561-QZ 12 mm 151 mm 98 mm 10 DT5562-QZ 12.5 mm 151 mm 98 mm 10
DT5563-QZ 13 mm 151 mm 98 mm 10
Qty
Aplication
Featuring a no slip shank to eliminate slipping in the chuck , these 1mm diameter EXTREME 2™ Metal Drill Bits are suitable for portable drilling of steel , alloyed and non-alloyed up to 900 N / mm2 .
72
