HEADQUARTERED IN SUWON, South Korea, Samsung, the multi-national electronics conglomerate, has a global presence with production facilities and distribution networks across 84 countries. The mainstay of, reputedly, the world’ s largest IT company, has been, and is, innovative technology which also drives Samsung’ s other core business- home appliances and, specifically, air conditioning. This was amply evident when Samsung convened its System Air Conditioning( SAC) Forum 2015 in late October 2015 at Seoul with the participation of more than 750 global partners and the media. The first of many to be held in the ensuing months, up to 1H 2016 in 117 cities offshore, the Forum aims to“ increase awareness of solutions among global trades and tech media and demonstrate Samsung’ s profound knowledge in the field of air solutions for the B2B market” and unveil Samsung’ s new range of innovative products in HVAC engineering, i. e.: � Samsung’ s New 360 Circular Cassette Design, innovative design that transforms air flow with a unique and revolutionary booster fan inside the 360 Cassette that guides air to form a complete horizontal flow, generating layers of chilled air. Samsung’ s circular air wave consistently controls the temperature of the room by providing an even distribution of air in a full 360 direction. Bladeless flow control ensures fast comfortable cooling without the cold draft by ensuring 100 % of air volume compared to traditional fourway Cassette units, which can lose up to 25 percent of air volume. The resulting cooling speed is increased by 34 %.

Elegantly designed to blend in with any setting, the unit features a stylish panel and intuitive display that allows users to change the air flow depending on preference, e. g., horizontal, vertical,

�

�

and separate zone control air flow. Ceiling-mounted or exposed to suit the style of any room, users have the option of a wheel dial remote controller with a dedicated button for comfort cooling. To eliminate dust, airborne contaminants, allergens, bacteria and viruses, the Samsung Virus Doctor kit can also be added. Samsung super Digital Variable Multiair conditioner DVM S 30HP with high-performance Variable Refrigerant Flow( VRF), the world’ s largest single unit with the efficiency, reliability and performance capabilities of four( saves space, dispenses with cooling towers), with a number of revolutionary features including a new Super Inverter Scroll Compressor with flash injection technology and an optimised by-pass valve location to increase heating capacity by 29 %.

The addition of a hybrid heat exchanger increases the heat exchange area while an optimised refrigerant control delivers greater efficiency( 10 %) and a new oval-shaped diffuser application improves the airflow path and increases the airflow rate by 17 %. The Samsung DVM S 30HP also complies with strict regulation thanks to an innovative leak detection system which automatically starts an active pump-down process to collect the refrigerant and close all valves to isolate the leak within the unit. Samsung DVM S Eco 14HP, a new side discharge VRF air conditioner engineered with improved performance to meet the growing need for a specialised single outdoor unit to reduce the cost of previous multipleloading and sub-duct installation in multi-room buildings. The increased horse power of the DVM S Eco( maximum 14HP) means that only one single outdoor unit is needed to

�

manage the air conditioning for an apartment or office building, in place of multiple costly units. All areas of the building are covered as the new unit also provides an extended piping length of up to 160 meters and an installation height of up to 50 meters. The innovative design of the DVM S Eco 14HP features a robust Inverter Scroll Compressor and corrugate fin, which improves heating performance by 20 percent and increases air flow by 10 percent compared to standard side discharge VRF units. Samsung DVM Chiller, in response to growing demand for water-source HVAC following the tightening of EU regulations on F-gas levels. An air-cooled chiller that offers greater energy efficiency and ease of use in an innovative compact design, the new DVM Chiller is a powerful system that combines an air-cooled chiller with VRF in a compact unit. By reducing refrigerant levels significantly more than a conventional chiller, the Samsung DVM Chiller complies with the current( 2015) and future( 2018) EU refrigerant quota levels.

In the revolutionary DVM Chiller, Samsung has embedded the worldclass BLDC Inverter Scroll Compressor with Flash Injection technology, ensuring over 75 % of heating capacity at-20 ° C ambient temperature and greater energy efficiency, enabling users to reduce annual utility costs by 36 to 50 % compared to conventional chillers. Also, the Samsung DVM Chiller delivers powerful heating performance while providing cold water through thermal ice storage with an in-built pressure and temperature sensor, which prevents device breakdown from freeze-bursts. �

For more information about SAMSUNG, visit www. samsung. com
