MEASURING INSTRUCTIONS:
™
ARMASSIST
STEP 3 CONT. - Measure Lengths
3. Measure the distal arm along dorsal aspect from elbow (as marked at the mid-point between Olecranon
Process and elbow crease) to the Ulnar Styloid as indicated on diagram and record length
in box marked Length C.
4. Measure hand from your mark on dorsal aspect of wrist to the third metacarpal head and record length in
box marked Length D.
5. Measure width of hand across dorsal metacarpal heads and record width in box marked E Width.
STEP 4 - Measure Circumferences
1. Encircle arm with a tape measure at each mark located between the elbow and axilla, and record each
circumference on the line corresponding to each position.
2. Encircle arm with a tape measure at each mark located between the elbow and Ulnar Styloid, and
record each circumference on the line corresponding to each position.
NOTES:
50
