H5 CORE
H5R CORE
H-SERIES CORE
LED
H5 CORE
H5R CORE
LED-Configuration 1x High Power LED 1x High Power LED Light Functions Boost / Power / Low Power Boost / Power / Low Power Luminous flux 1( lm) 350 / 200 / 15 500 / 300 / 15 Beam Distance 1( m) 160 / 120 / 30 200 / 150 / 30 Run Time 1( h)- / 2 / 20- / 2 / 50 Color temperature( K) 6000- 7500 6000- 7500 Color rendering index( CRI) 70 70
BATTERY AND CASE
Battery 2x Mignon( AA) Alkaline 1,5V 1x Li-ion Batterypack 3,7V Battery Capacity 2( Wh / mAh)- 6,66 / 1800 IP Level IP67 IP67 Rechargeable No Yes Charging Time 5( min)- 210 Drop height( m) 1,5 1,5
SIZE AND WEIGHT
Head diameter( mm) 32 32 Weight incl. Battery( g / oz) 178 / 6,3 167 / 5,9
TECHNOLOGY
Multi-Core Optics Flex Sealing Technology
FLEX SEALING TECHNOLOGY
Magnetic Charge System Fusion Beam
FUSION BEAM
Advanced Focus System
More features Cooling Technology, Dimmable, Transportation Lock, Energy Saving
PACKAGING
Cooling Technology, Temperature Control, Dimmable, Transportation Lock, Flicker-free, Memory Mode, Backup Mode, Battery Indicator, Charge Indicator, Low Battery Warning, Constant Light
Item no. Box / GTIN 502193 / 4058205020848 502121 / 4058205020879 Contents Box
1 set of batteries
1 set of batteries, magnetic charging cable
OPTIONAL ACCESSORIES more accessories on page 78 502451 Transp. Silicone Headband NEW 502256 Universal Mounting Bracket NEW 76
EVERYTHING ABOUT THE CORE – WORK – SIGNATURE CONCEPT FROM PAGE ► 22
