P6R CORE QC
P6R CORE QC
04
03
1 MULTICOLOR LED 4 COLORS
01 – Equipped with a Multicolor LED with white , red , green and blue light
02 – Multicolor Strobe – colored flashes of light with irritating glare effect for emergencies
03 – Easy Operation – the rotary switch enables quick color changes 04 – Advanced Focus System – stepless focusing
LED
LED-Configuration Light Functions ( white light )
P6R CORE QC
1x Power LED
Luminous flux 1 ( lm ) 270 / 120 / 15 Beam Distance 1 ( m ) 335 / 220 / 80 Run Time 1 ( h ) 5 / 14 / 110 Color temperature ( K ) 6000 - 7500 Color rendering index ( CRI ) 80 ( White light )
BATTERY AND CASE
Power / Mid Power / Low Power
Battery 1x Li-ion Batterypack 3,7V Battery Capacity 2 ( Wh / mAh ) 9,25 / 2500 IP Level Rechargeable
IP54
Yes Charging Time 5 ( min ) 200 Drop height ( m ) 1,5
SIZE AND WEIGHT
Length – defocused ( mm ) 157 Head diameter ( mm ) 42 Weight incl . Battery ( g / oz ) 207 / 7,3
TECHNOLOGY
Dual Power Source Rapid Focus Advanced Focus System More features
PACKAGING
Multicolor Strobe , Single Color Strobe
Item no . Box / GTIN 502517 / 4058205026819 Contents Box
1 battery set , lanyard , USB charging cable
OPTIONAL ACCESSORIES more accessories on page 61
502251 Lamp Adapter Type D
1-7
Information on page 184 58
