Technical Specifications
WATER
Pressure in dynamic range
Flow rate range
Inlet connection Maximum temperature
Value
Min 22 PSI- Max 44 PSI Regulator recommended Min 68 fl oz / min Electric( Approx) Max 85 fl oz / min Pneumatic( Approx) 3 / 8” barbed connector < 86 ° F
Recommended hardness < 8- 8.5 gpg( grains per gallon)
AIR( For pneumatic models)
PUMPS
PRODUCT / WATER VALVES
Booster tank
Water Pressure Regulator Working pressure Air intake Average consumption Air entrainment Condensation filter
Number
Flow rate( with water)
Body Membranes Non return valves Voltage Body Closure piston O-rings
Not included. Supplied on request. Recommended. Included 58 PSI 3 / 8” barbed connector 4.9 cubic feet per minute Optional Integrated 1 pump per channel. Main channel: electric diaphragm( depending on setup) Pneumatic double diaphragm pump( depending on setup) 51 fl oz per minute( Electric) 85 fl oz per minute( Pneumatic) PVDF PTFE PVDF / FFKM 24VDC PP PTFE FFKM
Standard measuring principle Paddles and Hall effect sensor.
FLOW SENSOR
DOSING
Signal Body O-rings Paddles
Alternative
Distribution Outlet barb diameter Outlet barb material Built-in tubes Recommended pipes for installation
24 VDC PNP PP FFKM PVDF * Oval gear not included. Supplied on request. Recommended with chemicals 180cP or higher. External distributor 3 / 8 inch connector PVDF EVA tube 10x16 mm & PTFE 10x12mm Braided( UK & US) PVC 10x16
