MAINTENANCE
When an acrylic-based resin is used as an application tool
for bike boxes, typically a municipality can expect to get
5 to 8 years of use from the application at a high-traffic
location. This assumes the application process follows all
manufacturer guidelines, which may include applying the
resin when ambient temperatures are within an acceptable
range and the pavement is free of any dirt. The ability
exists to refresh the markings when worn, as the resin acts
similarly to paint and can be reapplied.
Thermoplastic markings typically have a life cycle of 3 to
5 years. Similar to acrylic-based resin, the manufacturer
guidelines must be followed to ensure the application
process is done correctly. Application after significant
wear must be done by removing the thermoplastic and
reapplying.
Paint is the least expensive application that can be used for
bike boxes. However, it is easily worn by vehicle tires and
requires frequent reapplication.
RESOURCES
Videos
“How to Use a Bike Box” (2017). Ayres Associates.
Retrieved from: https://spark.adobe.com/video/
ZkZT4S8KM1gha
“2 Stage Left Turn for Bikes” (2013). Seattle Department
of Transportation. Retrieved from: https://www.youtube.
com/watch?v=5S_-JjsxZGU
“Bike Boxes and Beyond” (2015). City of Bellingham,
Washington. Retrieved from: https://www.youtube.com/
watch?v=Lf8-_uS-T_A
Articles & Blog Posts
“Wauwatosa East North Avenue Bike Lane Plan.” Ayres
Associates. Retrieved from: http://www.ayresassociates.
com/project/wauwatosa-east-north-avenue-bike-lane-
plan/
