GB
Burner and nozzle specifications
Table 1
Liquid Gas
Diameter
(mm)
Burner
Thermal Power
kW (p.c.s.*)
Nominal
By-pass Nozzle
1/100
1/100
(mm)
(mm)
Reduced
Natural Gas
Flow*
g/h
Nozzle
1/100
(mm) Flow*
l/h
*** ** Reduced Rapid (RR) 100 2.60 0.70 39 80 189 186 110(Y) 248
Semi Rapid (S) 75 1.65 0.40 28 64 120 118 96(Z) 157
Auxiliary (A) 55 1.00 0.40 28 50 73 71 71(X) 95
Triple Crown (TC) 130 3.25 1.50 61 91 236 232 133(Z) 309
28-30
20
35 37
25
45
Supply
pressures
*
**
***
A 15°C e 1013,25 mbar-dry gas
Propane
P.C.S. = 50.37 MJ/Kg
Butane
P.C.S. = 49.47 MJ/Kg
Natural
P.C.S. = 37.78 MJ/m 3
S
TC
PHN 942 T/IX/A
8
Nominal (mbar)
Minimum (mbar)
Maximum (mbar)
A
RR
20
17
25
