connection
diagram below. Electrical connection diagram is located on the bottom of the appliance.
Electrical Connection Diagram
INSTRUCTIONS FOR USE
- Use the induction cooking zones with suitable cookware.
- After mains voltage is applied, all displays are on for a moment. When this time is over, the
hob is in the standby mode and it is ready for operation.
-
The hob is controlled with electronic sensors which are operated by touching the related
sensors. Each sensor activate is followed by a sound signal (buzzer).
Switching the hob ON
Switch the hob on by touching the ON/OFF button
until all heater displays show a
static“0”and the bottom right dots blink. (If no cooking-zone is selected within 20 seconds, the
hob will switch off automatically.)
Switching the hob OFF
Switch the hob off at any time by touching
button .
button always has the priority in
the switch off function.
Switching the cooking-zones ON
After switching the hob on and placing the pot on the chosen cooking zone, adjust the power
level by
pressing the
button. There is a static dot indication on the selected heater display. Each
13
