GB
GLASS controls
Grease/odour fi lter warnings
The T2 icon fl ashes to indicate that the grease fi lter is
saturated, while T3 fl ashes to indicate that the odour fi lter
is saturated, and if both are fl ashing then both fi lters are
saturated. You must then clean/replace the grease fi lter (A)
or odour fi lter (B) or both, accordingly (see “Maintenance
and care”).
Models with mechanical keypad
HGA 9.5 AM X
T1
T2
T3
T4
T5
T1 Motor reset
Pressing the button while the hood is in operation turns it
OFF.
T2 Speed 1
Pressing the button sets the hood to speed 1.
To reset the fi lter counter:
Hold down T5 for three seconds while the hood is on.
The warning led fl ashes three times, then returns to its
normal mode If both fi lter warnings are active at the same
time, you must reset each separately.
The fi rst sequence resets the grease fi lter, while the second
sequence resets the odour fi lter.
Hood confi guration:
To set the operating mode of the hood, hold down T5 for 6
seconds while the product is off. Icons T2 or T3 will light up
to show the type of installation: T2 ventilation, T3 fi ltering.
You can change the type of installation by pressing T4
cyclically.
To save the new confi guration press T1 individually.
T3 Speed 2
Pressing the button sets the hood to speed 2.
T4 Speed 3
Pressing the button sets the hood to speed 3.
T5 Lights ON/OFF
Models with soft button keypad and display
Models with soft button keypad
(Only available in certain models)
HGF 9.5SS AB X
B
B
T1
T2
T3
T4
T5
T6
T1 Motor reset
Press the button with the hood off to set speed 1. Pressing
the button while the hood is in operation turns it OFF.
T2 Speed 1
Pressing the button sets the hood to speed 1.
T3 Speed 2
Pressing the button sets the hood to speed 2.
T4 Speed 3
Pressing the button sets the hood to speed 3.
T5 Booster
Pressing the button sets the hood to high speed. After 5
minutes, the hood returns to the previous speed; pressing
a speed button (T2, T3 or T4) quits booster mode and sets
the selected speed.
T6 Lights ON/OFF
T1 T2 T3
1 Motor ON/OFF
Press the button with the hood off to set speed 1. Pressing
the button while the hood is in operation turns it OFF.
T2 Speed -
Pressing the button returns the hood to the previous speed.
T3 Speed +
Pressing the button returns the hood to the next speed.
T4 Booster
Pressing this button sets the hood to high speed; the letter
"b" fl ashes slowly on the display. After 5 minutes, the hood
returns to its previous speed; this can also be done while
booster mode is on by pressing either speed button (T2
or T3).
T5 Timer
Pressing this button delays the hood turning off automatically
by 5 minutes. The timer counts down on the display in
minutes. The timer can only be set for manual speeds, not
for booster mode.
T6 Lights ON/OFF
16
T4 T5 T6
