Rentable area : 18,750m 2 Lifts are standard Melco / Mitsubishi .
Unitised Panel Elements The glazing / panel types are as follows :
• Type 1 : Outer pane : 6,38mm laminated Ener- G-Smart Neutral safety glass ; 12mm gap ; Inner pane : 6mm clear toughened safety glass . U value : 2 W / m 2 . K
• Type 2 : Single glazed spandrel : 6.38mm laminated Ener-G-Smart Neutral safety glass ; Air gap : 50mm from glass to back pan . Powder coated back pan with 40mm thermal insulation .
Retains a glass aesthetic without compromising insulating qualities . U-value : 0.5 W / m 2 . K
• Type 3 : 4mm composite aluminium coil faced panel , colour to be specified . 40mm thermal insulation to specification .
• Type 4 : 6mm Eclipse Advantage grey toughened safety glass . U-value : 3.4 W / m 2 . K
• Type 5 : 6mm Eclipse advantage grey safety glass ; powder coated galvanised back panel colour QQL 258 charcoal ; 40mm thermal insulation ; powder coated internal aluminium panel , colour QQX 202 Matt new Silver . U-value : 3.9W / m 2 . K
Alice Lane Phase 1 203
