Type 2: Single glazed spandrel: 6.38mm
laminated Ener-G-Smart Neutral safety
glass; Air gap: 50mm from glass to
back pan. Powder coated back pan with
40mm thermal insulation to specification.
This was to retain a glass aesthetic
without compromising insulating qualities.
U-value: 0.5 W/m2.K
Type 3: 4mm composite aluminium coil
faced panel, colour to be specified. 40mm
thermal insulation to specification.

Alice Lane

Type 4: 6mm Eclipse Advantage grey toughened safety glass. U-value: 3.4 W/m2.K
Type 5: 6mm Eclipse advantage grey safety
glass; powder coated galvanized back panel colour
QQL 258 charcoal; 40mm thermal insulation;
powder coated internal aluminium panel, colour
QQX 202 Matt new Silver. U-value: 3.9W/m2.K

The development
required the demolition
of the existing Standard
Bank building

Roof Area
There is 300m2 of open space on the roof which
has been provided for use by the gym.
