ARCHITECTURAL FOCUS
Technical sheet Name: Wave 4 & WAVE 5 | ECR Health Care Complex Location: 64 Polna Street, 81-740 Sopot, Poland Program( Use): Pre- and post-procedure medical care; rehabilitation centre( laser therapy, cryotherapy, hyperbaric chamber, movement therapy); 44 supervised patient rooms; restaurant( ground floor, Wave 4, open to the public) Site Area: 5 hectares( ECR complex) Building Area:( WAVE 4) 2.957 m2 +( WAVE 5) 1.787 m2 = 4.744 m2 Structure: Steel frame with reinforced concrete; 4 above-ground floors per building; Wave 4: 2 basement levels, Wave 5: 1 basement level; above-ground height approx. 20 m; deep foundation works due to high groundwater levels and non-bearing soil conditions Finishes— Exterior: Laminam Bianco Assoluto sintered ceramic panels( outer facades); perforated aluminium panels with“ Flower of Life” pattern( shutter system); Aluprof external profile systems( windows and facades); external timber decking( untreated) Finishes— Interior: Laminam ceramic wall panels; Italgraniti and Refin Ceramiche wall and floor tiles; Appiani and The Mosaic Factory mosaic finishes( pool and bathrooms); Interface carpeting( corridors); ShowTex stretch ceilings( corridors); Isinac acoustic ceiling panels; bespoke plywood carpentry by FAAB; True Design Italia free-standing furniture Design Team: FAAB Architektura( architects and interior designers) Collaborators: Structural engineering: Statikus; Sanitary and electrical engineering: Profen Sp. z o. o.; Landscape architecture: iGreen Client: Grupa Invicta Sp. z o. o. Photographer Credits: Jakub Certowicz, Dario Breggiè
faab. pl
ARCHETECH- PAGE 114
