The firm’ s winning proposal centered around its embrace of a new and innovative approach to the massive nine-block development.
“ The complex houses nine departments, but the requirements for each of them were independent and filled with contradictions,” explains Yunchao Xu, lead architect of Atelier Apeiron.“ We approached it from the perspective of integrating nine independent buildings into a single complex, and we convinced the client to give each department relative independence in order to proceed with a comprehensive strategy that resolves conflicts and stimulates public energy.”
Innovative responses The unique setting of the Hengqin Culture & Art Complex was not without its challenges. The region’ s status as a typhoon-prone area in summer was a challenge requiring special considerations, including numerous wind-resistant material comparisons before deciding upon a light and flexible suspended glass curtain wall as a particularly efficient solution. Another challenging element was how to introduce natural light into such large volumes.
Being on an island with a sub-tropic climate, the foundations of the expansive complex also presented a challenge, with a natural layer of silt that can cause stability issues. In response, the firm designed a basement as a sealed support space with anchor points to ensure maximum strength throughout the structure.
Gateways of arts and culture The site of the Hengqin Culture & Art Complex is wedged between existing residential towers and an open city park, and Atelier Apeiron devised a strategy for creating an energetic complex capable of accommodating a multifunctional future. As part of that strategy, the firm espoused an architectural approach defined by large-scale porosity, adapted to the high-density urban context of the site’ s surroundings.
On the lower level of the complex, Apeiron applied a geometric concept of inverted catenary to create three magnificent arches of differing shapes, articulating an architectural language that combines Chinese and Western elements. Each arch serves as a gateway to a different hall that is unique in both character and program. To draw natural light into the inherently dark spaces, the firm cut a skylight above the arches to form connections with the rooftop gardens, and also incorporated two diffuse reflectors that direct soft sunlight into the rooms.
Composed of wood and bamboo panels, the arches provide a window of transparency between the facility and its surrounding urban life. By day, visitors will enjoy unobstructed external views of the adjacent park, while nights will be illuminated by the soft lighting emitted by the transparent arched halls, forming a stage background for a variety of public events to be held in the park.
“ Arches have been embraced as a critical form of architecture since the beginning of time and are prevalent in both eastern and western culture,” explains Yunchao Xu.“ To create strong structures with available materials, arches have been used to convert shear force in a horizontal direction into vertical force, ensuring that all points of the structure carry a shared load.”
Above the archways, modular space units have been integrated into the design to ensure maximum flexibility options for a wide variety of future programs. Additionally, small spaces have been integrated into the arch joints to house equipment and building services.
