Prefabricated Utility Cupboards & HIU
The YGHP Prefabricated MEP Utility Cupboard offers complete control
and design to meet exact project requirements.
The advantages of a MEP
utility cupboard are great
as they can:
Reduce project costs.
Reduce projec time.
Reduces project labour
hours.
Fit and forget.
Tailored to suit specific
project requirements.
Can include equipment
such as: HIU, CIU UFH,
MVHR, heat pumps or hot
water cylinders.
The COST EFFECTIVE, STABLE PERFORMING HIU
Heat interface units are a complete solution for apartments, for
hydraulic separated systems.
Secondary system: radiators or underfloor heating.
Balancing valves can be radiators or underfloor heating.
Stainless steel heat exchanger and thermostatic controlling valve
to have a stable temperature domestic hot water up to 35 it/min.
Stainless steel heat exchanger is used to hydraulically separate the
apartment from the primary system.
Thermostatic controlled valves are used to control the secondary
side supply temperature.
Energy efficient electronically controlled pump controls the flow of
secondary side heating.
All the consumption of heating and domestic hot water
preparation can be measured by one heat meter and cold
water meter.
All the piping is stainless steel (insulated)
