MAGPLY BOARDS FRONT SIP
SOLUTION FOR STUDENT
ACCOMMODATION ON THE
SOUTH COAST
A high rise development in
Bournemouth for Fresh Student
Living is making full use of the
technical benefits to an innovative
BBA approved structural walling
system, which features 9mm
Magply boards for both the inner
and outer faces to the insulated
panels’ design. It has been built by
main contractor, the Watkins Jones
Group, with MIB Façades being the
specialist sub-contractor erecting its
own SIPs system.
www.magply.co.uk
23
ISOPRO® AND ISOMAXX® BALCON™
Concrete Balcony Connection
Systems offer the best insulation
performance, with higher load
capacity and faster Installation. Steel Balcony Connection System
offers easy balcony positioning
tolerance with excellent load
capacity. Thermal insulation
performance to meet part L.
• Cost-effective, high-quality
performance components
• Faster installation with no need to
tape joints.
• Blank inserts of the same
insulation material to optimize
design/cost
• Easy to cut to length when
needed
• No moisture absorption by the
insulation layer to reduce thermal
performance.
• Very low deflection at the
connection to the structure
For more information and advice
please contact J&P Building
Systems ltd.
www.jp-uk.com
• Designed for your specific
balcony to concrete connection.
• Cost-effective, high quality
components
• Excellent thermal insulating
properties
• Easy to set into position with no
need to cut edge shutter
• High load performance with fast
installation
• Very low deflection at the
connection to the structure
• Now an approved LABC
Registered Detail
For more information and advice
please contact J&P Building
Systems ltd.
www.jp-uk.com
24
DUBLIN APARTMENTS USE
OFFSITE SYSTEM FEATURING
MAGPLY PERFORMANCE
The full range of performance
benefits to Magply boards have
been utilised in the specification of
an advanced offsite system being
employed in the construction of a
new apartment building standing
alongside a famous central Dublin
landmark on Amiens street.
Linham Construction is the main
contractor and developer for the
Five Lamps project, which is creating
ten single bedroom apartments plus
a two-bedroom, duplex property.
The structure has been designed
and specified by Building Surveying
consultants, Merriman Solutions,
to achieve an A1 Building Energy
Rating under Part L of the Building
Regulations. Edge structural
engineers provided structural
engineering for the LGS frame.
www.magply.co.uk
While many such composite walling
solutions use OSB or particleboards
to sandwich a foam insulation
core, the MIB MetSIP is much more
robustly engineered, with 75 mm
deep cold-formed steel Sigma
studs – plus a 45mm treated timber
packer - at 600mm centres.
