Bucher E35m mechanical profile
Sweeper Drain Valve
Sweeper Drain Ports
CAUTION : Before you get started with any maintenance , make sure to take the following safety precautions :
• Ensure the machine is standing on firm , level ground and that there are no obstructions above before raising the hopper .
• Ensure the safety props are always used when working under the hopper .
• Ensure operators are fully conversant with the controls and operation .
• Isolate the air in the systems locker before working on any pneumatically operated or controlled equipment .
• Disconnect vehicle battery when working on the electrical system .
• Ensure the engine is switched off once the pickup broom has been lowered for adjustment .
• Keep hands , loose clothing , hair , etc ., well clear of moving parts .
• Do not grasp any part of the engine or exhaust system without first making sure that it has cooled sufficiently to avoid scalding .
• Do not disconnect hydraulic or water pipes while the engine is running .
• Do not use ill-fitting tools such as spanners that may slip and cause injury .
• Always get a second person to check periodically that all is well when only one person is working on the machine or under the hopper .
MECHANICAL SWEEPER CHECKLIST :
Elevator : Chains , flights , flight rubbers , position cylinders , chain tensions , floor plates , and position switches
Sweep gear : Rear broom , gutter broom brushes , gutter cylinders , drag shoes , rear broom arms , rear broom dampers , overcenter lift assembly , rear broom cover , rear broom swivel bearing , and rear broom spherical bearing
Systems locker : Rear broom and elevator manifold , hopper manifold , gutter broom manifold , pneumatic valve manifold , water manifold , and oil cooler .
Hopper : Entire hopper , tip cylinder , pressure control manifold , door cylinder , position switch , and lift cylinders .
Water system : Water tank , filter assembly , and pump .
Subframe : PTO pump and scissor lift
Cab : Control panel , and relay box .
CYLINDER MAINTENANCE : Periodically inspect the cylinder rods for damage , blemishes or buildup of material such as tar , cement , paint , etc . The rods can be cleaned with fine wire wool and / or spirit to ensure long seal life . When cleaning the machine , avoid playing the washdown hose over the body tip cylinder when in the fully raised position .
CLEANING THE VEHICLE : Care should be taken when using high pressure steam and washdown equipment , as damage can be caused by playing this equipment onto the engine , electrical control systems , and paintwork , etc ..
While these winterization tips can help protect your sweeper investment , all equipment eventually meets its end of productive life . When it is finally time to retire your faithful sweeper after years or decades of faithful service , we have a free industry report : The 5 Things You MUST Know BEFORE Buying a Street Sweeper .
To learn more , visit www . buchermunicipal . com / us / en . To book a demo , please call us at 704-658-1333 .
Matt Starnes is the Product Marketing Manager for Bucher Municipal North America , Inc . headquartered in Mooresville , North Carolina .
