Protected environment

INTEGRATED SYSTEMS
Workplace safety - for patient , dentist and assistant alike - depends on the effectiveness of integrated systems , and Anthos has one for every need . The Full
Touch panel gives users full control over devices and also can be used to manage individual sanitisation or disinfection cycles .
BIOSTER and FLUSHING The automatic BIOSTER system performs intensive disinfection of instrument spray internal circuits with an antiseptic liquid ( Peroxy Ag +). Each stage of the cycle is controlled by the software and settings can be personalised by the user . FLUSHING gives the spray ducts a fast rinse to eliminate any stagnant liquid from tubing . Its use is recommended every morning when the surgery opens .
DVGW CERTIFICATE The dental unit body is EN 1717 compliant .
Systems control . Because all systems are fully integrated with the dental unit electronics , dentist and assistant can monitor and personalise procedures via the Full Touch display .
S . H . S . The device that feeds water to the sprays as an independent alternative to mains water is supplied as standard . Works by way of a tank filled with distilled water : this prevents limescale build-up . Extremely useful where mains water is hard .
A . C . V . S . Automatic system for the flushing and cleaning of the suction system . Allows sanitisation to be performed between one patient and the next .
O . D . R . As-standard mechanism that automatically emits an air jet to clean any residual liquids or solids from the handpiece after use .
SAFETY
A combination of active devices and constant defence against contamination form the bedrock of the Anthos hygiene system . Careful design of dental unit components at risk of contamination makes surface cleaning tasks easier and more effective . Safety in the surgery is further enhanced by the presence of removable parts and suitable materials .
Cuspidor bowl unit . Fully removable for fast , effective sanitisation , the cuspidor bowl unit consists of parts that are easy to clean and disinfect ( ceramic as standard or , as an optional , glass ).
Double filters . These easily removable filters make emptying and cleaning tasks simple .
Upholstery . Easy-to-sanitise , durable seamless padding .
Handpiece support . Instrument support mat in autoclavable silicone .
Removable instrument levers . The optional SideFlex instrument levers can be removed to aid cleaning tasks .
42 CLASSE R7 .
