tools
510-0864
Dealer Service Kit for Street Legal Exhaust
550-1129 S & S exhaust gasket installation tool Say goodbye to the struggle of handling fragile exhaust gaskets with the S & S exhaust gasket installation tool. Designed to make exhaust gasket installation effortless, the tool attaches to a 3 / 8” drive socket extension for precise gasket positioning.
tools
The primary inner bearing race installation tool features a roller thrust bearing that reduces installation effort by 30 %, helping the race press on smoothly and evenly. 56-5145
530-0084
530-0038A
S & S Engine Stands A practical, cost-effective solution for securing an engine on the workbench, during transport, or for display applications. This stand delivers stable support without overcomplicating the job.
S & S Cycle Torque Plates are the right tool for your shop to ensure accurate boring and honing. Made from heat treated Steel and designed to fit stock through 4.320 bore cylinders, these torque plates give you the precision you need for performance builds.
530-0072
53-0013 The S & S crankcase oil passage drilling jig is used to perform crankcase drilling modifications when installing an S & S oil pump assembly on early big twin crankcases. Made of hardened steel for durability, this fixture enables the builder to do four modifications:
• Primary chain oil supply passage from the breather valve gear cavity to the back side of the oil pump body on late generator and early alternator crankcases.
• Pressure relief passage from behind the main oil pressure valve to the gear cavity on alternator crankcases.
• Crankshaft and main bearings supply passage on generator crankcases.
• Crankshaft and main bearings supply passage on early alternator crankcases
The 2023 CVOs come with a lot of perks, and one major drawback: changing anything in the cam chest with Variable Valve Timing requires a special tool. Luckily, the crew at S & S are on it with their Cam Phaser Tool! The new S & S Cam Phaser Tool holds the cam phaser assembly in place to allow you to pull the Spool Valve Bolt and get access to the cam plate, oil pump, and, of course, the cam. If you’ re planning to do any work inside the cam chest of these new CVO models.
DESCRIPTION S & S PART #
Tool, Kit, Gasket, Installer, Straight and Tapered............................................. 550-1129 Tool, Kit, Inner Primary Race Installer......................................................... 56-5145 Dealer Kit, Service, S & S ®, Tamperproof Screw................................................... 510-0684 Torque Plate Kit for Stock- 4.320” Bore Cylinders 2017-up M8................................. 530-0038A Torque Plate Kit for Stock to 4” Bore Cylinders on 1999-’ 17 bt................................. 530-0084 CVO Cam Phaser Tool............................................................................ 530-0072 Stand, Engine, Packaged, 2017-Up M8 Touring, 2018-’ 20 Softail ®................................. 530-0068 Stand, Engine, Packaged, Blue, 2000-up bt w / Balancer........................................... 53-0145 Stand, Engine, Packaged, Blue, 1999-2006 bt..................................................... 53-0143 Stand, Engine, Packaged, Blue, 1936-’ 99 bt...................................................... 53-0141 Jig, Drill, Oil Passage, 3 / 8” x 1” x 2.75”, 1953-’ 80 bt......................................... 53-0013
MADE IN USA
15
