Ness Enterprises first announced its partnership with Taiwan ' s Rough Crafts ( founded by former World Championship custom bike builder Winston Yeh ) around 18 months ago , and since that time it would appear that the biggest problem the collaborators have had has been keeping product on the shelf at the Dublin , California Ness HQ warehouse - such has been the demand . Despite the logistics and supply chain issues affecting the custom parts and accessory industry , back in May Ness announced new deep-fill inventory
Round air cleaner
availability , including of the Rough Crafts ' design , Ness tech equipped air cleaner options and M-8 cam cover and rocker box designs seen here . Available in CNC machined fin round and retro teardrop styles , these Rough Crafts air cleaner designs for 2017 and up M-8 models feature much of the advanced Arlen Ness air cleaner technology that is used in its own Deep Cut and other custom performance air cleaner ranges . Made in forged black anodized billet aluminium , the smooth CNC sculpted low profile teardrop shaped intake means greater legroom clearance as well as improved air flow performance through the radius air inlet for increased horsepower , torque and mileage . Features include the patented and award-winning Arlen Ness hidden breather system and oil catch reservoir to eliminates oil blow-bye issues on M-8 engines . In the Ness next generation hidden breather technology , each hidden breather is o-ringed at the
Finned air cleaner
heads , passes through the backing plate and exits inside the mouth of the throttle body through proprietary shooter tubes . This eliminates the need for any external hoses or hardware for a virtually closed loop system . Specially designed breather bolts are hidden under billet covers for a clean look . The bolt-on design allows the oil catch to be serviced when the service filter element is serviced , but by
Rocker box covers
ensuring that no oil saturates the reusable and washable high performance black pre-oiled air filter by collecting any excess engine oil before it reaches the air filter , the system enhances service life as well as performance . Selected fitments are available for Twin Cams , Touring and Softail M-8 , Sportster , Dyna and Trike from 199 and up . The black anodized Rough Crafts designed M-8 rocker box covers seen here " feature CNC sculpted fins inspired by the engine itself . CNC machined from forged billet aluminum , they replace the OEM diecast rocker box tops , ship with all necessary hardware and are a great match for the additional Rough Crafts accessories , including grips and peg designs ." Also seen here , this black anodized Rough Crafts designed M-8 cam cover is a CNC machined 6060- T6 forged billet aluminium replacement for the
Cam cover
die-cast OEM cam cover , and comes with hardware and engraved with the Rough Crafts logo .
ARLEN NESS ENTERPRISES Dublin , California , USA Tel : 925 479 6350 contact @ arlenness . com www . arlenness . com www . roughcrafts . com
PanAm Oil Shut-Off Valves
German parts and accessory specialist W & W Cycles ( Wuerzburg ) says that the spring loaded ball check valves ( to prevent engine oil from seeping down to the crankcase ) in Pre-Twin Cam engines " don ' t last forever " and that " if you try to start such an engine after a lengthy period of inactivity ( over winter for example ), the oil in the crank case can get forcefully ejected via the breather . " This creates an ungodly mess . The conventional fix is to install a manually operated valve in the oil feed line from tank to oil pump can prevent this - but that carries the risk of forgetting to open it , resulting in major engine trouble . And we mean major . " Our preferred and recommended fix is this nifty PanAm shut off valve . It too is also installed in the feed line , but there is one major difference - once closed , the ignition is cut out too . There is no inadvertent starting of the engine with this baby . " The tough chrome plated polyamide housing has several mounting holes which offer all sorts of possibilities to secure it to the frame or other convenient hard points . It fits Big Twins up to the introduction of the Twin Cam in 1999 using 3 / 8 " internal diameter hoses . It measures 31 mm wide , by 42 mm high and 45 mm deep and comes with 30 cm long wires .
W & W CYCLES AG Wuerzburg , GERMANY Tel : + 49 ( 0 ) 931 250 6116 sales @ wwag . com www . wwag . com
Stock Wheel Replacement Rotors
These gold rotors by Lyndall Racing Brakes are a bolt-on replacement for ' 14- ' 22 Harley-Davidson Touring models with ' Prodigy ' or ' Enforcer ' wheels . Manufactured in stainless steel , it is an 11.8 " spokemounted rotor with five bolt holes with 6.7 " brake rotor pitch circle diameter ( PCD ). They will also fit H-D ' Aggressor ' front wheels when used with ' Enforcer ' style bolt hats . Drag Specialties , USA , www . dragspecialties . com , www . lyndallbrakes . com
54 AFTERMARKET MOTO DESIGN - AUGUST 2022 www . AMDchampionship . com
