HEALTH AND SAFETY •

A SPOTLIGHT ON FOG PREVENTION

PART 2 : SIBANYE-STILLWATER HIGHLIGHTS CHALLENGES IN UNDERGROUND LIGHTING

By Sharyn Macnamara
African Mining turns the spotlight on the Sibanye-Stillwater Rustenburg operations – specifically Khuseleka shaft 1 , in part 2 of a series of articles discussing the importance and benefits of adequate lighting to miners in underground environments , particularly in light of preventative measures in fall of ground ( FOG ) incidents .

Join African Mining , incorporating Mining Mirror as we descend to a depth of 986m from surface with Eric Cilliers , acting VP Engineering and Marko le Roux acting engineering manager Sibanye-Stillwater at Khuseleka shaft , 1 where the company is trialling lighting solutions to ‘ engineer out ’ the risk in in-stope illumination . Here the team have uncovered and are in the process of solving some of the challenges . The mantra at Khuseleka is “ together we shine ,” which is particularly apt in the face of what the industry is trying to achieve with lighting and in this particular case study .

Setting the scene En route underground , the team set the scene for us in detail . FOG incidents have historically been number one cause of fatalities in the mining industry in South Africa and the majority of these accidents happen in areas zero to four metres from the stoping face in conventional mines . Miners must rely on their cap lamps for illumination and rockfall hazard identification underground . This lighting is often insufficient , and this forms the crux of the challenge , and has led to underground workface illumination case studies conducted by Minerals Council members to investigate solutions to improve the ability that the workforce has to identify FOG hazards in this area of a mine .
Sibanye-Stillwater has taken a phased approach to in-stope illumination solution seeking in collaboration with the Minerals Council ever since the FOGAP ( Fall of Ground Action Plan ) 2 was adopted by the CEO Zero Harm Forum , and workface visibility was identified as a quick-win project . Sibanye-Stillwater investigated , sourced and purchased LED lighting strips for trials , taking occupational health considerations and MOSH-approved Improved Underground Workface Visibility Leading Practice in 2022 into account . In 2023 these strips were installed in various work faces across several of the company ’ s operations to determine practicality , robustness and efficiency , and these trials are still in progress .
“ Every day we send people down into an ever-changing potentially hazardous environment ,” said Cilliers . “ For us as leaders to enable our employees to identify hazards to the best of their ability is the way forward . These trialled lighting solutions will lead the way to solutions that will assist with safety and operational excellence and will become industry best practice .” Sibanye-Stillwater intends on making underground illumination and improved underground workface visibility one of their minimum standards .
All photos by © Sharyn Macnamara , African Mining
Left to right : Eric Cilliers , acting VP engineering ; Marko le Roux , acting engineering manager Sibanye-Stillwater and Hennie Bodenstein , appointed mine overseer at Khuseleka shaft .
Illuminating the challenges “ Due to the changes in face configuration and ground conditions after a blast - the entry examination is the most important period of the cycle and miners need the maximum and safest illumination available at this point to check hang and features on the face , to make the area ready and safe for the drilling team . One of the biggest challenges has been to find a practical solution based on the unique design of each operation . The illumination solution is dependent on the layout of the operation and where the power supply is located – and each operation is different .”
Cilliers explains that the team has achieved quick wins by illuminating underground areas used by trackless mobile machinery ( TMM ), development ends , travelling ways and cross cuts , which can use a higher voltage LED strip-light illumination . “ Sibanye-Stillwater ’ s modern trackless operations have also rolled out high-voltage , mobile spotlights to assist with the examination of bords where a bord and pillar mining method is used .”
In contrast , Khuseleka case study has proved to be a more challenging environment , primarily due to the fact that the operation utilises a conventional mining method . Conventional stopes are significantly narrower than mechanised stopes , which have an immediate limitation when using low-voltage LED strips , where LED lumen performance is reduced by the length of face as well as the distance to the electrical outlet . Many conventional underground mines in South Africa face the added risk of methane
