Animating 3d motion
Finally, you’ll add a title and animate it in 3D space. Animating in 3D presents
the added complication of a third (z) axis. When you choose the 3D Rotation or
3D Translation tool, you need to be aware of the Global Transform option at the
bottom of the Tools panel. The Global Transform option toggles between a global
option (button depressed) and a local option (button raised). Moving an object
with the global option on makes the transformations relative to the global coordi-
nate system, whereas moving an object with the local option on makes the transfor-
mations relative to itself.
1 Click on Scene 1 to return to the main timeline and insert a new layer at the top
of the layer stack and rename it title.
2 Lock all the other layers.
3 Insert a new keyframe at frame 120.
4 Drag the movie clip symbol called movietitle from the Library panel onto
the Stage.
The movie title instance appears in your new layer in the keyframe at frame 120.
