MAPAL already engineered the machining of the engine blocks for the predecessor 3.6-litre diesel engine , which meant they were able to draw on practical experience and didn ’ t have to start from scratch .
For example , the tool experts already knew which machines the engine manufacturer has from previous projects . DEUTZ has equipped its assembly line in Zafra with new five-axis machines over recent years , so they can switch to new products with relative ease .
When DEUTZ sent their request , the Tool Management department in collaboration with the Technology Expert Team ( TET ) in Aalen first gave some thought to the production process . “ To be quick here , we don ’ t concern ourselves with detail at this early stage , but instead pull together reference tools and concepts from previously completed projects ”, explains Harald Traub from TET .
He is responsible for planning the entire process as Project Engineer . “ In this way , we are able to specify an approximate budget and the rough scope of the tool package for the client .”
One hundred different tools for an engine block
After this rough planning , the concrete tool design followed in the second week . MAPAL ’ s offer for the series production of the motor block included almost 100 different tools in the end . Many of them are custom tools that achieve short machining time and thus high economic efficiency . Aside from these , standard tools are used for milling above all .
To produce prototypes quickly , a few close-tostandard tools were also used . Series production can then begin with the optimal set of tools .
As part of their original delivery , MAPAL supplied consumable tools as well as the required tool holders and adapters to DEUTZ . All other consumables will be handled by the tool management on site . From this point on , the client no longer pays per tool but per completed part – i . e ., the cost per part is billed .
The unit costs at first correspond to the price determined during engineering . Certain ratios have been agreed upon for the following years . The client receives an increasing percentage of rebate and therefore pays a bit less per unit every year . For this business model to work out , MAPAL has to implement continual improvements to save costs . This is done with new tool technologies and corresponding optimisation .
The costs per part are fixed over the term of the contract , after which a reassessment takes place . Such contracts , which run over four to five years , offer the client planning security .
“ With our engineering expertise , we support DEUTZ beyond the tool-setting area and cultivate a close partnership ”, Spang highlights . After helping to build the prototype , it is the tool management ’ s turn to shine on-site during series production . DEUTZ uses approximately 1,300 different tools in total . Thousands of tools are available from stock and have to be managed in Zafra .
To keep inventory at an optimal level ( i . e ., avoiding bottlenecks while preventing unnecessarily high tool stocks ), MAPAL uses its own warehouse management systems and digital solutions with the cloud-based software c-Com for tool management . The digital Tool Management 4.0 doesn ’ t only handle procurement processes , which are initiated semi-automatically , it also acts as a reporting tool to analyse cost drivers and stocks .
Tools just in time for the assembly line
Industrialization Manager Manuel Rodríguez López praises the good collaboration with MAPAL when it comes to tool management : “ Over the course of our cooperation , we have developed extensive technological concepts , which go far beyond mere logistics . Besides achieving cost reductions , tool setting is particularly important for us .
The MAPAL employees working on-site have a lot of know-how and ensure that production has exactly the tool they need at the right time .”
MAPAL ’ s tool manager on site is David Castaño . MAPAL also employs tool setters permanently in Zafra . They make sure that a dozen different parts are produced without a hitch . “ It is very beneficial to have David here on-site with us ”, emphasises Manuel Padilla Fernández , Manufacturing Engineering Manager at DEUTZ , who works closely with the tool manager . “ We can talk about any opportunities for optimisation directly at the machine . We don ’ t consider David Castaño to be an external service provider but rather a part of our team . It ’ s a very strong cooperation .”
Developing together to solve problems
If required , new tool solutions can be developed in Aalen via the local MAPAL team . That was the case in Zafra when it became necessary to optimise the tools for machining the bore in the crankshaft and camshaft .
In cooperation with DEUTZ , a new machining concept from MAPAL with the HPR400 reamer was implemented . David Castaño is convinced of its advantages : “ The tool life of the previous tool was 350 units and resetting was required every 100 units . With the HPR400 , we achieve a tool life of 1,000 parts without resetting . The resulting machining quality is exceptionally good .”
For more information , please visit www . mapal . com
