Knock-in dowels
Pre-mounted 10
Fast fixing
Pre-mounted 10
Different blocks can be combined with Slide-on mounting plates 37x32 euroscrews fixing, to solve particular mounting problems. The inclined bloc, symmetrical, can be mounted at positive or negative angles with respect to the sides.
SP6B01 |
SP6B02 |
SP6B03 |
SP6B04 |
SP2401 chromed |
SP2402 chromed |
SP2403 chromed |
SP2404 chromed |
Screw V226 / G |
Screw V223 / G |
|
|
Screw V224 / G |
Screw V223 / G |
B1051MG15M1
B1051MG30M1
B1051MG45M1
B1051MG60M1
B1051ZG90M1
BLITZ B5011MG15E2
B5011MG30E2
B5011MG45E2
B5011MG60E2
B5011ZG90E2
Mounting plate with fast fixing system BLITZ
Blitz is the new fixing system that makes easier and faster the mounting by only half turn of the screwdriver. The screw is completely inserted in the dowel to avoid the accidental dismounting during transport. the 10mm diamater expandable dowels assures a perfect strenght with alla types of materials. Minimum encumbrance and mounting times drastically reduced.
New adjustable plate
With the patented cam system the door can be vertically and parallely adjusted ensuring a perfect door strenght in any position and preventing any door sag.
COMPASSO plate
Compasso is the first mounting plate that allows any door angle inclination with standard plate position. Angle inclination can be adjusted from 5 ° to 22 ° also with plate and door mounted. Compasso can be supplied with pre-set angle inclination according to customer’ s needs, quantities have to be agreed with Ferrari sales managment.
Ferrari 61
