483760 Edition II II | Page 244
245 |
Complete
5ACC..FS, 5ACC..FT
5ACC..GC
Fixed Non-Ventilated Curb
Grease Collector
Manufactured from heavy gauge galvanized steel.
Corners are welded construction. The curb features
fiberglass insulation that deadens sound and minimizes
heat loss. The unit equipped with shutter flanges and 1
1/ ” and a wood nailer (fixed roof curbs only). Class 2.
2
The grease collector box manufactured from
heavy gauge galvanized steel. It fastens to a ventilator base. Easy to remove for cleaning. Diverts
and traps heavy residual grease while protecting
roof surface. Available in 2 sizes. Class 1.
Specification Data
Specification Data
Model
8”/ 12”
Fan Size
Weight,
lbs
Item #
List Price,
USD
Model
8”/ 12”
Fan
Size
Length,
inch
Width,
inch
Weight,
lbs
Item #
List Price,
USD
5ACC15FS
REC 54/6
24
49580
111.00
5ACC00GC
10 - 13
14
5
4
47178
109.00
5ACC19FS
REC 8..10
24
471062
140.00
5ACC01GC
15 - 36
24
7
12
47180
140.00
5ACC17FS / 5ACC17FT
10
24 / 29
47206 / 47207
124.00 / 159.00
5ACC20FS / 5ACC20FT
12, 13
28 / 33
47212 / 47213
137.00 / 171.00
1ACC..CS
5ACC24FS / 5ACC24FT
15, 16
33 / 38
47217 / 47941
148.00 / 185.00
Ceiling Mount Shutter
5ACC28FS / 5ACC28FT
18, 20
40 / 48
47221 / 47222
166.00 / 206.00
5ACC32FS / 5ACC32FT
24
46 / 53
47226 / 47227
184.00 / 227.00
5ACC40FS / 5ACC40FT
30
57 / 68
47233 / 47901
232.00 / 353.00
5ACC44FS / 5ACC44FT
36
68 / 73
47237 / 47238
268.00 / 339.00
5ACC..VC
Specification Data
Fixed Ventilated Curb
Model
Manufactured from galvanized steel. The curb features
stamped louvers on curb sides that provide ventilation to
hot exhaust ducts to protect building and roof members.
Self-flashing design incorporates flat mounting flange
for fastening directly to the roof deck.
Recommended
Opening, inch
Free area,
sq.ft.
Weight,
lbs
Item #
List Price,
USD
1ACC24CS
24
24 x 24
4
4
49932
126.00
30
30 x 30
6.25
4
47885
158.00
1ACC36CS
36
36 x 36
9
5
47610
189.00
Weight,
lbs
Item #
List Price,
USD
1ACC..MD
Model
Fan Size
Curb Height,
inch
Weight,
