SER 11504
Commercial Energy Recovery Ventilator
The SER Series lowers demand on air conditioning systems. Air supplied from
outdoors enters through the energy recovery core where it transfers the heat
and moisture the incoming air to the outgoing air that was cooled and dried by
the building’s air conditioner. The air brought into the working area is cooled
and the humidity is reduced for maximum comfort. Reduces the load on an air
conditioner to save on cooling costs. This unit is designed for warmer, humid
climates with longer cooling seasons.
Applications include classrooms, retail shops, hair salons, bars and restaurants,
offices, clinics, and animal shelters, etc.
Airflow up to 1132 cfm @ 0.4” Ps
Push-push configuration
External low voltage contacts
No defrost
Dual service doors & reversible electrical box
External three position switch (Low/Standby/Medium)
Improved BMS integration
•
•
•
•
•
•
•
Maximum continuous airflow
in.wg
0.3” Ps
0.4” Ps
0.5” Ps
0.6” Ps
0.7” Ps
0.8” Ps
0.9” Ps
1.0” Ps
1.1” Ps
1.2” Ps
1.3” Ps
1.4” Ps
1.5” Ps
Supply air flow (high)
1176
1132
1088
1045
1001
958
914
870
827
783
739
696
652
Exhaust air flow (high)
1176
1132
1088
1045
1001
958
914
870
827
783
739
696
652
cfm
Energy performance
Supply temperature
Net Airflow
Sensible recovery efficiency
Latent recovery efficiency
Total recovery efficiency
F
cfm
%
%
%
35
1050
61
31
51
35
788
68
41
55
O
Heating
95
1050
58
24
37
95
Cooling
788
64
30
43
Specification data
SER 11504
fantech
Voltage /
phase
Rated
power
Max
amps
Average airflow @
0.4” Ps
V/~
Model
W
A
cfm
120
1272
10.6
1132
Connection
Defrost
cycle
Side
Auto
Shipping
weight
Item #
lbs
278
List price
USD
44927
5,020.00
