2SHE Series
Direct Drive Shutter Fans
Fantech, Inc. certifies that the
Shutter Mounted Exhaust Fans
shown herein are licensed
to bear the AMCA Seal. The
ratings shown are based
on tests and procedures
performed in accordance with
AMCA Publication 211 and
AMCA Publication 311 and
comply with the requirements
of the AMCA Certified Ratings
Program.
Shutter mounted exhaust fans are widely used for ventilating warehouses,
stores, factories, workshops, greenhouses and farm buildings. Shutter
frames with prepunched mounting holes allow for easy installation.
•
•
•
•
•
•
•
All ventilators are UL 705 Standards listed
Heavy duty guards have gray polyester coating to resist corrosion
OSHA compliant guards
Totally enclosed motors
Speed controllable (except 2SHE 30C1 and 2SHE 36D1)
Shipped ready to install
2SHE07 thru 2SHE24 blades are manufactured from aluminum,
2SHE30 and 2SHE36 blades are manufactured from galvanized steel.
Specification data
Rated
power
Voltage /
phase
RPM
HP
V/~
min-1
2SHE 0721
1/30
120 / 1
2SHE 1021
1/30
120 / 1
Model
Bearing
type
Amperage
full load
0.0” Ps
0.125” Ps
1725
Sleeve
1.4
140
1585
Sleeve
1.4
585
0.25” Ps
Sones
@ 0.0” Ps
Shipping
weight
-
-
4.8
285
-
6.6
Amps
cfm
Item #
List price
15
47096
148.00
10
47097
150.00
lbs
USD
2SHE 1221
1/30
120 / 1
1570
Sleeve
1.4
800
470
-
7.6
21
47098
159.00
2SHE 1621
1/20
120 / 1
1550
Sleeve
1.5
1095
720
-
8.0
19
47099
208.00
2SHE 1871
1/15
120 / 1
1075
Sleeve
1.2
1860
850
-
8.4
22
47100
272.00
2SHE 20B1W
1/4
120 / 1
1150
Sleeve
4.6
2830
2250
1235
11.3
39
47102
357.00
2SHE 24B1W
1/4
120 / 1
1150
Ball
3.7
3240
2485
1110
11.4
39
47103
421.00
2SHE 30C1
*
1/3
120 / 1
850
Ball
4.4
6075
4195
2150
13.5
65
47104
536.00
2SHE 36D1*
1/2
120 / 1
850
Ball
5.6
8225
6480
2935
14.7
75
47105
611.00
Performance certified is for installation type A, Free Inlet, Free Outlet. Speed (RPM) shown is nominal. Performance is based on actual speed of test. Performance ratings include the effects of guard and shutter.
The sound ratings shown are loudness values in fan sones at 5 ft in a hemispherical free field calculated per AMCA Standard 301. Values shown are for Installation Type A, Free Inlet hemispherical sone levels.
*
Single speed motor
