Grow
2VLD Series
Direct Drive Medium Duty Propeller Fans
Fantech, Inc. certify that the Axial
Ventilators shown herein are
licensed to bear the AMCA Seal.
The ratings shown are based on
tests and procedures performed
in accordance with AMCA
Publication 211 and AMCA
Publication 311 and comply with
the requirements of the AMCA
Certified Ratings Program.
Medium duty exhaust fans are designed for general ventilation in dusty, dirty
and grease or moisture-laden environments.
•
•
•
•
Wire guards and venturi panels have baked-on gray polyester finish
to help resist corrosion
Totally enclosed, sleeve bearing
Speed-controllable
Shipped ready to install
Specification data
2VLD 1221
Rated
power
Voltage /
phase
Amperage
full load
RPM
HP
Model
V/~
Amps
min-1
1/30
120 / 1
1.4
1550
0.0” Ps
0.125” Ps
845
665
0.25” Ps
0.375” Ps
Sones
@ 0.125” Ps
Shipping
weight
-
7.8
14
cfm
315
Item #
List price
47114
154.00
lbs
USD
2VLD 1661
1/20
120 / 1
1.6
1520
1170
885
560
-
13.6
18
47115
203.00
2VLD 18B1
1/4
120 / 1
3.9
1150
2500
2130
1590
1025
10.4
28
47116
323.00
2VLD 20B1
1/4
120 / 1
4.9
1165
3440
2995
2310
1450
12.5
36
47117
362.00
2VLD 24B1
1/4
120 / 1
4.1
1150
3455
2985
2410
1580
12.8
36
47118
443.00
Performance certified is for installation type A: Free Inlet, Free Outlet. Speed (RPM) shown is nominal. Performance is based on actual speed of test. Performance ratings include the effects of shutter and guard.
The sound ratings shown are loudness values in fan sones at 5 ft. (1.5 m) in a hemispherical free field calculated per AMCA Standard 301. Values shown are for Installation Type A, hemispherical sone levels.
