165 |
Grow
FADE Series
Axial Fans
Fantech’s FADE Series axial fans are designed to effectively and quietly handle
major ventilation challenges in locations such as large warehouses without
taking up a lot of valuable space.
Fantech, Inc. certifies that
the models shown herein are
licensed to bear the AMCA
Seal. The ratings are based
on the tests and procedures
performed in accordance with
AMCA Publication 211 and
comply with the requirements
of the AMCA Certified Ratings
Program. Performance certified is
for installation type D – Ducted
inlet, Ducted outlet. Performance
ratings do not include the effects
of appurtenances (accessories).
FADE WHD Series*
All FADE Series fans combine aerodynamically designed propeller blades
and rotor motor into one expertly integrated unit. Fans feature a heavy gauge
galvanized steel and powdercoated finish casing. With fan sizes ranging from
8” to 25”, Fantech’s FADE Series fans move a lot of air, yet are statically and
dynamically balanced for vibration-free operation. The external rotor motorized
propeller provides excellent heat dissipation, even at low RPM. Rated for
continuous duty.
•
•
•
•
•
Airflow up to 7858 cfm
100% speed-controllable
Shallow profile with no protruding motor
Suitable for airstream temperatures up to 100° F
All fans include motor side guards as standard
FADE Series
Specification data
Model
Rated
power
Voltage /
Phase
W
Max.
Amps
RPM
0.0” Ps
0.1” Ps
0.25” Ps
A
0.375” Ps
0.5” Ps
Sones†
cfm
Weight
Item #
List price
lbs
USD
FADE 8-4
45
120 / 1
0.411
1550
304
246
74
-
-
4.1
15
411298
239.00
FADE 10-4
68
120 / 1
0.621
1500
624
558
377
132
-
7.9
15
411350
273.00
FADE 12-4 / FADE 12-4 WHD
130
120 / 1
1.191
1400
1208
1069
797
-
-
9.4
20
411351 / 45422
329.00 / 579.00
FADE 14-4 / FADE 14-4 WHD
245
120 / 1
2.24
1200
1839
1654
1295
-
-
9.6
20
411352 / 45423
406.00 / 634.00
FADE 16-4 / FADE 16-4 WHD
458
120 / 1
1
2.70
1400
3054
2882
2570
2198
1699
12.0
25
411353 / 45424
484.00 / 813.00
FADE 18-4 / FADE 18-4 WHD
698
120 / 1
6.392
1550
4115
3895
3549
3239
2908
14.3
30
411299 / 45425
757.00 / 1,024.00
FADE 20-4 / FADE 20-4 WHD
1450
120 / 1
2
8.39
1450
4949
4682
4274
3917
3445
16.4
45
411354 / 45427
902.00 / 1,246.00
FADE 20-6 / FADE 20-6 WHD
435
120 / 1
3.981
1100
3693
3368
2775
1429
-
10.7
45
411300 / 45426
818.00 / 1,169.00
FADE 22-6 / FADE 22-6 WHD
756
120 / 1
6.92
1000
5629
5248
4432
-
-
12.0
55
411305 / 45429
1,125.00 / 1,481.00
FADE 25-6 / FADE 25-6 WHD
1134
120 / 1
10.38
1000
7858
7355
6557
-
-
14.8
65
411355 / 45431
1,330.00 / 1,692.00
1
2
3
Performance certified is for installation type A - Free inlet, Free outlet. Speed (RPM) shown is nominal. Performance is based on actual speed of test. Performance ratings include the effects of intake guard.
The sound ratings shown are loudness values in fan sones at 5ft (1.5m) in hemispherical free field calculated per AMCA Standard 301. Values shown are for installation type A, free inlet hemispherical sone
levels.
*
WHD model fan is fully assembled and includes a wall cabinet and a backdraft damper
1
Recommended speed control rating 5A 2 Recommended speed control rating 10A 3 Recommended speed control rating 15A
