Make
5FSU Series
Filtered Supply Unit
Fantech, Inc. certifies that the
Ventilators shown herein are
licensed to bear the AMCA
Seal. The ratings shown are
based on tests and procedures
performed in accordance with
AMCA Publication 211 and
AMCA Publication 311 and
comply with the requirements
of the AMCA Certified Ratings
Program.
Belt-drive filtered supply units are designed to be installed on the roof or wall
(15” and 18” units roof-mount only). The single-sided units provide filtered
supply air to industrial and commercial buildings and can easily be used in
commercial or industrial kitchen applications. Units include one set of 1”
washable aluminum filters.
•
•
•
•
•
All ventilators are UL 705 Standard listed
AMCA licensed for sound and air
Lifting lugs are standard on all sizes for ease of transport
Galvanized metal housing and base
Variable pitch sheaves to allow speed and CFM adjustments
Specification data
Rated
power
Voltage /
phase
RPM
HP
V/~
min-1
5FSU 10BB
1/4
120/230 / 1
689
5FSU 10CB
1/3
120/230 / 1
760
5FSU 10DB
1/2
120/230 / 1
870
5FSU 10FB
1
120/230 / 1
1090
5FSU 12EB
1
120/230 / 1
725
5FSU 15FB
1
120/230 / 1
670
5FSU 15GB
1-1/2
120/230 / 1
745
5FSU 18GB
1-1/2
120/230 / 1
592
0.125” Ps
0.25” Ps
0.375” Ps
0.50” Ps
Model
0.75” Ps
1.00” Ps
1.25” Ps
cfm
fantech
Item #
lbs
Max BHP † | LWA #
1647
1387
1044
184
-
-
-
0.29 | -
0.29 | 81
0.29 | -
0.29 | -
-
-
-
1863
1637
1377
697
-
-
-
0.38 | -
0.38 | 82
0.38
