Cook

5DDU Series
Direct Drive Upblast Roof Ventilators

Fantech, Inc. certifies that
the Direct-Drive Upblast
Centrifugal Roof Ventilators
shown herein are licensed
to bear the AMCA Seal. The
ratings shown are based
on tests and procedures
performed in accordance with
AMCA Publication 211 and
AMCA Publication 311 and
comply with the requirements
of the AMCA Certified Ratings
Program.

Direct-drive upblast ventilators are designed for continuous operation to exhaust
foul air, smoke, fumes, odors and grease-laden vapors from range hoods
and commercial cooking appliances. Ventilators are designed for installation
in industrial, institutional and commercial kitchen applications. All models
are equipped with a backward inclined aluminum fan wheel and a speed
controllable motor.
•

•
•
•
•

All ventilators are listed UL 705 for electrical and UL 762 for
restaurant exhaust except for 5DDU085AY
Inlet temperatures up to 300°F
Backward inclined aluminum fan wheel
Externally cooled motor compartment
Fully welded windband

Specification data
Rated
power

Voltage /
phase

RPM

HP

V/~

min-1

5DDU 085AY

1/25

120

1642

5DDU 106A

1/20

120

1100

5DDU 10AA

1/6

120

1725

5DDU 12CA

1/3

120

1557

5DDU 13DB

1/2

120/230

1690

5DDU 15CA

1/3

120

1144

5DDU 16DB

1/2

120/230

1145

5DDU 18EB

3/4

120/230

1111

0.0” Ps

0.125” Ps

0.25” Ps

0.375” Ps

Model

0.50” Ps

0.625” Ps

0.75” Ps

1.00” Ps

cfm

Shipping
weight

Item #

lbs

Sones † | BHP
416

349

267

169

-

-

-

-

8.0 | -

7.1 | -

6.5 | -

6.8 | -

-

-

-

-

685

548

388

116

-

-

-

-

5.1 | -

4.5 | -

3.9 | -

4.1 | -

-

-

-

-

979

911

836

749

650

522

-

12.3 | -

11.6 | -

11.3 | -

10.6 | -

10.8 | -

10.5 | -

-

1531

1469

1406

1340

1272

1193

1107

897

13.8 | 0.27

13.5 | 0.29

13.3 | 0.31

12.9 | 0.32

12.6 | 0.33

12.3 | 0.34

12.0 | 0.35

11.3 | 0.33

2419

2352

2285

2218

2145

2072

1992

1829

20 | 0.54

20 | 0.55

19.5 | 0.56

19.0 | 0.58

18.6 | 0.59

18.2 | 0.60

17.9 | 0.62

17.4 | 0.63

2174

2070

1963

1849

1714

1568

1375

13.0 | 0.28

12.5 | 0.30

12.0 | 0.31

11.4 | 0.32

10.8 | 0.32

USD

10.0 | 0.32

2859

2739

2619

2494

2369

2219

2063

1502

15.6 | 0.41

15.0 | 0.43

14.5 | 0.45

13.7 | 0.47

13.2 | 0.48

12.6 | 0.49

12.2 | 0.49

11.0 | 0.46

3899

3787

3644

3495

3337

3181

3011

2616

21 | 0.73

21 | 0.75

20 | 0.78

19.8 | 0.80

18.9 | 0.81

18.0 | 0.83

17.3 | 0.84

16.9 | 0.85

23

47333

294.00

37

47334

375.00

88

47335

428.00

109

47337

508.00

117

47339

696.00

130

1048
12.6 | -

13.5 | 0.27

List price

47340

963.00

144

47342

1,017.00

159

47343

1,124.00

Performance certified is for installation type A: free inlet, free outlet. Performance rating includes the effects of bird screen. Speed (RPM) shown is nominal, and performance is based on actual speed of test.
†
The sound ratings shown are loudness values in fan sones at 5 ft. (1.5m) in a hemispherical free field calculated per AMCA standard 301. Values shown are for installation type A, free inlet hemispherical sone
levels.
