139 |
Cook
5DDU EC Series
Direct Drive Upblast Roof Ventilators
Fantech, Inc. certifies that
the Direct-Drive Upblast
Centrifugal Roof Ventilators
shown herein are licensed
to bear the AMCA Seal. The
ratings shown are based
on tests and procedures
performed in accordance with
AMCA Publication 211 and
AMCA Publication 311 and
comply with the requirements
of the AMCA Certified Ratings
Program.
Upblast ventilators are designed for continuous operation to exhaust foul air,
smoke, fumes, odors and grease-laden vapors from range hoods and commercial
cooking appliances. Ventilators are designed for installation in industrial,
institutional and commercial kitchen applications. 5DDU-EC Series feature
energy saving EC motors, which are ideal for applications requiring demand
control ventilation, for example, apartment buildings, multi-purpose rooms with
differing rates of ventilation, hi-rise buildings - single fan on riser exhausting
multiple spaces or restaurant applications with grease laden air.
Factory preassembled with rpm speed control card with automation capability.
Module can easily be mounted in optional NEMA 3R enclosure on the outside of
the fan or inside the building.
•
•
•
•
•
•
•
All ventilators are UL 705 and UL 762 Standards listed
Driven by EC Technology
Inlet temperatures up to 300°F
Soft start-software provides overload protection
Runs at optimal load due to the integrated electronic controls
Multiple controller options
2-10 VDC signal for manual control
Specification data
Rated
power
Voltage /
phase
RPM
HP
V/~
min-1
5DDUEC 10EN
3/4
120/208/240
5DDUEC 12EN
3/4
5DDUEC 13EN
3/4
5DDUEC 15FN2
5DDUEC 18FN
Model
*
*
0.0” Ps
0.25” Ps
0.50” Ps
2060
1186 | 239
1052 | 250
908 | 262
120/208/240
1835
1951 | 435
1846 | 465
120/208/240
1685
2495 | 564
2376 | 586
1
120/208/240
1755
3252 | 977
1
120/208/240
1300
4840 | 1239
0.75” Ps
0.875” Ps
1.00” Ps
1.25” Ps
Sones
@ 0.25”
748 | 271
657 | 268
554 | 261
175 | 203
15.4
85
49821
1,328.00
1737 | 478
1625 | 482
1565 | 480
1495 | 477
1348 | 477
17.8
92
49822
1,508.00
2254 | 608
2112 | 623
2040 | 630
1955 | 632
1780 | 634
18.9
95
49823
1,575.00
3087 | 973
2922 | 968
2742 | 962
2654 | 959
2563 | 956
2383 | 950
24
105
49824
1,800.00
4570 | 1253
4292 | 1260
3983 | 1246
3828 | 1242
3670 | 1240
3350 | 1239
19.7
161
49826
1,935.00
cfm | Watts
Shipping
weight
Item #
lbs
List price
USD
Performance Certified is for Installation type A: free inlet, free outlet. Performance rating includes the effects of a bird screen. Speed (RPM) is nominal and performance is based on actual speed of test. Values
shown are for installation type A, free inlet hemispherical sone levels.
*
The Sound ratings shown are loudness values in fan sones at 5 ft. (1.5m) in a hemispherical free field calculated.
