Cook
5BDU Series
Belt Drive Upblast Roof Ventilators
Fantech, Inc. certifies that the
Belt-Drive Upblast Centrifugal
Roof Ventilators shown herein
are licensed to bear the AMCA
Seal. The ratings shown are
based on tests and procedures
performed in accordance with
AMCA Publication 211 and
AMCA Publication 311 and
comply with the requirements
of the AMCA Certified Ratings
Program.
Belt-drive upblast ventilators are designed for roof mounted exhaust
of commercial and industrial buildings. There models are both for roof and wall
application (except 5BDU30 and 5BDU36). Durable spun aluminum construction
with steel support braces. Backward inclined aluminum fan wheel. Motor and
wheel are easily detachable without removing ventilator from curb. Permanently
lubricated ball bearings (5BDU10 - 5BDU13) and regreasable pillow block
bearings (5BDU15 - 5BDU24).
•
•
•
•
•
All ventilators are listed UL 705 for electrical and UL 762 for restaurant
exhaust in USA only
Models 5DBU10 - 5BDU24 are suitable for wall application
Inlet temperatures up to 300°F
Fully welded windband
Externally cooled motor compartment
Specification data
Rated
power
Voltage
RPM
HP
V
min-1
5BDU 10BB-A
1/4
120/230
1819
5BDU 12CB-A
1/3
120/230
1566
5BDU 13DB-A
1/2
120/230
1530
5BDU 15EB-A
3/4
120/208-230
1489
5BDU 15FB-A
1
120/208-230
1639
5BDU 16FB-A
1
120/208-230
1400
5BDU 18FX-A *
1
208-230/460
1169
5BDU 18GB-A
1-1/2
120/208-230
1338
5BDU 18HX-A (*)
2
208-230/460
1473
5BDU 20GB-A
1-1/2
120/208-230
1155
0.0” Ps
0.125” Ps
0.25” Ps
0.375” Ps
Model
0.50” Ps
0.625” Ps
0.75” Ps
1.00” Ps
cfm
Shipping
weight
Item #
lbs
Sones † | BHP #
1179
1138
1089
1037
981
922
855
679
15.1 | 0.22
14.7 | 0.23
14.3 | 0.23
13.5 | 0.24
13.1 | 0.24
12.8 | 0.25
12.0 | 0.25
10.6 | 0.24
1530
1473
1417
1358
1290
1223
1142
961
13.1 | 0.28
13.1 | 0.29
12.7 | 0.30
12.7 | 0.31
12.3 | 0.31
11.7 | 0.32
11.0 | 0.32
10.3 | 0.32
2188
2115
2042
1966
1888
1808
1723
1538
17.3 | 0.42
17.0 | 0.44
16.3 | 0.45
16.2 | 0.46
15.4 | 0.48
15.4 | 0.49
15.1 | 0.50
13.6 | 0.50
2811
2735
2659
2582
2503
2414
2325
2123
18.1 | 0.66
17.9 | 0.67
17.8 | 0.69
17.7 | 0.70
17.1 | 0.72
16.9 | 0.73
16.5 | 0.74
15.7 | 0.74
3094
3025
2956
2886
2817
2743
2662
2501
20 | 0.87
20 | 0.89
20 | 0.91
19.2 | 0.93
19.1 | 0.94
18.9 | 0.96
18.8 | 0.97
18.2 | 0.97
3674
3576
3478
3388
3282
3175
3068
2844
21 | 0.91
21 | 0.92
21 | 0.94
19.8 | 0.95
19.6 | 0.97
19.6 | 0.98
18.6 | 0.99
17.4 | 1.02
3986
3873
3756
3640
3508
3368
3229
2914
17.6 | 0.82
17.3 | 0.84
17.5 | 0.86
17.1 | 0.88
16.9 | 0.90
16.3 | 0.92
16.2 | 0.93
15.4 | 0.94
4563
4465
4363
4261
4159
4045
3923
3678
21 | 1.23
21 | 1.25
20 | 1.28
20 | 1.30
20 | 1.32
19.5 | 1.35
19.1 | 1.36
18.2 | 1.39
5023
4935
4842
4750
4657
4564
4459
4238
25 | 1.64
24 | 1.67
24 | 1.70
23 | 1.72
23 | 1.75
22 | 1.77
22 | 1.79
21 | 1.83
5367
5227
5086
4947
4797
4640
4483
4136
22 | 1.31
21 | 1.34
21 | 1.38
21 | 1.41
20 | 1.43
19.8 | 1.46
19.2 | 1.47
18.4 | 1.50
List price
USD
110
46800
803.00
120
46802
888.00
132
46805
958.00
150
46811
1,097.00
153
46813
1,097.00
154
46820
1,166.00
201
46828
1,305.00
214
46829
1,402.00
210
46831
1,498.00
216
46839
1,445.00
Performance certified for installation type A: free inlet, free outlet. Performance rating includes the effect of bird screen.
#
Power rating (BHP) does not include transmission losses.
†
The sound ratings shown are loudness values in fan sones at 5 ft. (1.5m) in a hemispherical free field calculated per AMCA standard 301. Values shown are for installation type A, free inlet hemispherical sone levels.
* 3 phase motor
fantech
