Cook
| 110
Balanced ventilation
for a residential kitchen
Your makeup air solution should be simple,
yet effective. The Fantech makeup air system,
along with a kitchen exhaust solution, will be
quiet, comfortable and reliable. Under ideal
conditions, even while preparing the largest and
most demanding meals, your kitchen remains
ventilated, without pulling in air from every crack
and crevice in your home. At Fantech, we hope
that you don’t have to think about our products,
because once they’re installed, they simply work
- leaving you to enjoy the truly important things
in your home.
142.-
$
Roof Cap
RC 10
2
1
3
LD 10
Silencer
FG 10
Inline Centrifugal Fan
227.-
$
4
SHL 42
Kitchen Hood Liner
1,134.-
$
Installation can be stand alone where the
makeup air is delivered into the kitchen or close
to the exhaust appliance, or it can be ducted into
the return air duct of a forced air/heating system
shown here. The inline duct heater and damper
can be controlled by a pressure switch from the
exhaust duct or current sensing switch from the
exhaust fan. Control of the supply fan can be
through the exhaust hoods integral variable
speed control if of sufficient amperage, or if the
control is push button by adding simple speed
controls on the low and medium load legs.
327.-
$
Kitchen Exhaust Solution
1. FG 10 / $327.Inline Centrifugal Fan
3. LD 10 / $227.Silencer
2. RC10 / $142.Roof Cap
4. SHL 42 / $1,134.Kitchen Hood Liner1
1
kitchen hood liners can support fans with total max of 6 Amps
Makeup Air Solution
1. FG 10 / $327.Inline Centrifugal Fan
3. LD 10 / $227.Silencer
5. EM-WX 10 / $975.Duct Heater2
6. FGR 10 / $150.Filter Cassette
7. ADC 10 / $119.Shut-off Damper
2
optional for cold climates
To learn more about these products, see pages
XXX and XXX.
