8-2. Steps to take in an emergency
599
NOTICE
n To prevent damage to the vehicle when towing using a wheel-lift type truck
When raising the vehicle, ensure adequate ground clearance for towing at the opposite end of the
raised vehicle. Without adequate clearance, the vehicle could be damaged while being towed.
n Towing with a sling-type truck
Do not tow with a sling-type truck to prevent body damage.
Using a flatbed truck
When using a flatbed truck to transport the vehicle, use tire strapping belts. Refer to the owner’ s manual of the flatbed truck for the tire strapping method.
In order to suppress vehicle movement during transportation, set the parking brake and turn the power switch off.
Emergency towing
If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing eyelet. This should only be attempted on hard surfaced roads for short distances at under 18 mph( 30 km / h).
A driver must be in the vehicle to steer and operate the brakes. The vehicle’ s wheels, drive train, axles, steering and brakes must be in good condition.
Emergency towing procedure
To have your vehicle towed by another vehicle, the towing eyelet must be installed to your vehicle. Install the towing eyelet using the following procedure. 1 Take out the towing eyelet.
( �P. 620)
2 Remove the eyelet cover using a flathead screwdriver.
To protect the bodywork, place a
rag between the screwdriver and the vehicle body as shown in the
illustration.
8
When trouble arises
