6-4. Using the other interior features
521
When the door is opened and closed, charging may be temporarily suspended.
lWhen charging, the wireless charging device and portable device will get warmer, however
this is not a malfunction. When a portable device gets
warm while charging, charging
may stop due to the protection function on the portable device
side. In this case, when the temperature of the portable device drops significantly, charge again.
The fan may start operating to
lower the temperature inside the wireless charger, however this is
not a malfunction.
n Operation sounds
A buzzing noise may be heard when pressing the power switch to turn to ACC or ON or when detecting a portable device. However, this is not a malfunction.
n Cleaning the wireless charger �P. 546
n Situations in which the function may not operate normally
Devices may not be charged normally in the following situations.
lThe portable device is fully charged
lThe portable device is being charged with a cable connected
lThere is foreign matter between the charge area and portable device
lCharging has caused the portable device to heat up
lThe temperature around the wireless charger is 35 ° C( 95 ° F) or higher, such as in extreme heat
lThe portable device is placed with its charging surface facing up
lThe small portable device such as
foldable type is placed in an area misaligned from the charge area
lThe portable device is larger than the charging tray
lThe camera lens protrudes 3 mm( 0.12 in) or more from the surface of the portal device
lThe vehicle is in an area where
strong electrical waves or noise are emitted, such as near a television tower, power plant, gasoline
station, broadcasting station, large display, airport, etc.
lThe electronic key is not inside the vehicle
lAny of the following objects is stuck or installed between the
charging side of the portable
device and the charge area.
• Thick cases or covers
• A case or cover attached with an uneven or tilted surface, so that the charging side is not flat
• Thick decorations
• Accessories, such as finger rings, straps, etc.
• Cover to protect camera lens
lWhen there is a gap between the charging side of the portable
device and the charge area due to a protrusion such as a camera on
the charging side of the portable device.
lWhen the portable device is in
contact with, or is covered by any of the following metallic objects:
• A card that has metal on it, such as aluminum foil, etc.
• A pack of cigarettes that includes
aluminum foil
• A wallet or bag that is made of metal
• Coins
• A heating pad
• CDs, DVDs or other media
• A metal accessory
• A case or cover made of metal
• A flip type case with a magnet on the charging side of the portable device
lElectric wave type wireless remote controls are being used nearby
l2 or more portable devices are
6
Interior features
