2-2. Charging
123
Likely cause
AC charging connector is not connected to vehicle
AC charging connector was connected after set time
Correction procedure
Before using the charging schedule, connect the AC charging connector.
Connect the AC charging connector before the time set in“ Start”.
When the charging mode is set to“ Start and stop”, the traction battery will charge even if the start time has passed, if the AC charging connector is connected before the stop time.
2
*: For details on setting the clock, refer to the separate“ MULTIMEDIA OWNER’ S MANUAL”. n Charging starts, even though charging schedule is registered
Likely cause
“ Charge Now” is set to on
Charging schedule is set to off
The charging mode is set to“ Start and stop” and the AC charging connector was connected between the start time and stop time
Correction procedure
When charging according to the charging schedule, set“ Charge Now” to off.( �P. 107, 110)
Check that charging schedule is not set to off.( �P. 109)
When the charging mode is“ Start and stop”, connecting the AC charging connector after the start time will perform charging until the stop time. Check the charging schedule.
Electric Vehicle system
