7-3. Do-it-yourself maintenance
523
• While registering ID codes, it may not be possible to change between wheel sets normally. Cancel registration before changing between wheel sets.
n Changing ID codes between different wheel sets
1 Install the desired wheel set.
2 Select on the multimedia display.
3 Select“ Vehicle customize”. 4 Select“ Tire pressure”.
5 Select the wheel set(“ Set 1” or“ Set 2”) displayed for the set selection setting.
6 Select the wheel set you wish to register, and then select“ OK”.
The tire pressure warning light will slowly blink 3 times, a message
indicating that change is occurring
will be displayed, and the wheel set change will begin.
Wheel set change will begin and the tire pressure warning light will
blink for 1 minute and then illuminate. Also, while the change is being performed,“---” will be displayed for the tire inflation pressure of each tire on the multi-information display.
After approximately 2 minutes, the wheel set change will complete, the tire pressure warning light will turn off, and a completion message will be displayed on the multi-information display.
If changing does not complete after approximately 4 minutes, a message indicating that the change
could not be completed will be displayed.
Check which wheel set is installed and perform the change procedure again from the beginning.
7 If the specified tire inflation pressure of the wheel set installed differs from that of the previous set, it will be necessary to perform the tire inflation pressure setting procedure of the tire pressure warning system.( �P. 518)
If the specified tire inflation pressure is the same, it will not be necessary to perform the tire inflation pressure setting procedure.
8 Register the position of each wheel.( �P. 517)
7
Maintenance and care
