7-3. Do-it-yourself maintenance
521
The ID code registration procedure cannot be performed while the vehicle is moving.
3 Select on the multimedia display.
4 Select“ Vehicle customize”. 5 Select“ Tire pressure”.
6 Check if the desired wheel set(“ Set 1” or“ Set 2”) is displayed.
ID codes will be registered to the displayed wheel set.
To change the wheel set to be registered, select the displayed set, and then select the wheel set you wish toregister.
If ID codes have already been registered for that wheel set, the tire pressure warning light will slowly blink 3 times, and a message indicating that change is occurring will be displayed on the multi-information display.
7 Select“ New tire registration”. 8 Select“ Continue”.
The tire pressure warning light will slowly blink 3 times and a message indicating that ID code registration is being performed will be displayed on the multi-information display. Wheel set changing will be canceled and registration will begin.
When registration is being performed, the tire pressure warning light will blink for approximately 1 minute then illuminate and“---” will be displayed for the inflation pressure of each tire on the multi-information display.
9 Drive straight( with occasional left and right turns) at approximately 25 mph( 40 km / h) or more for approximately 10 to 30 minutes.
When registration is complete, the
tire pressure warning light will turn off and a message indicating that
registration has been completed
will be displayed on the multi-information display.
Registration may take longer than normal to complete if the vehicle speed cannot be maintained at approximately 25 mph( 40 km / h) or more. If registration cannot be completed after driving for 1 hour or more, perform the registration procedure again from the beginning.
10If the tire inflation pressure of the wheel set installed differs from that of the previous set, it will be necessary to perform the tire inflation pressure setting procedure of the tire pressure warning system.( �P. 518)
If the specified tire inflation pressure is the same, it will not be necessary to perform the tire inflation pressure setting procedure.
nWhen registering ID codes
lNormally, wheel position registration can be completed within approximately 30 minutes.
lID code registration is performed while driving at a vehicle speed of approximately 25 mph( 40 km / h) or more.
lID codes can be registered by yourself, but depending on the
7
Maintenance and care
