2-2. Charging
101
WARNING
lDo not connect conversion adapters, extension cords, etc. other than those provided by SUBARU, between the DC
charging connector and charging inlet.
lWhen DC charging is interrupted, follow the handling procedures of the DC charger. Immediately stop the DC
charging when there is an outbreak of heat, smoke, strange
noises or smells, etc., during charging.
lCheck that the DC charging connector and charging inlet do not have foreign objects or snow or ice attached to it. If anything is attached to the inlet, be sure to completely remove the material before connecting the DC charging connector.
lDo not charge the vehicle when there is a possibility of lightning. If you notice lightning while charging the vehicle, do not touch the vehicle and the DC charging cable.
lDo not get the charging inlet terminals wet.
lClose the hood when using DC charging. The cooling fan may suddenly
start to run. Keep hands and clothing( especially a tie, a scarf or a muffler) away from the fan.
Failure to do so may cause the hands or clothing to be caught, resulting in serious injury. n When connecting the DC charging connector
lFollow the handling procedures of the DC charger to connect the DC charging connector. If
the connector is not connected properly, the system cannot recognize the connection, and it
may be possible to start the EV system.
lDo not remove the DC charging connector from the charging
inlet during DC charging. After operating the DC charger to
stop charging, remove the DC
charging connector from the charging inlet.
NOTICE n When using DC charging
Make sure to follow the handling procedures of the DC charger. If the procedures are not followed properly, the vehicle and the DC charger may be damaged.
After charging
1 Operate the DC charger and stop the charging.
The DC charging connector will be unlocked when charging is completed, while carrying the electronic key on your person or when the doors are unlocked.
2 Remove the DC charging connector.
The DC charging connector shape and treatment will differ depending on the type of DC charger.
Perform the operations in accordance to handling procedures of the DC charger.
Return the removed DC charging
2
Electric Vehicle system
