7-3. Do-it-yourself maintenance
581
●When using a wheel set which all of the ID codes have already been registered, the wheel set can be changed in a short amount of time.( �P. 581)
■ If ID codes are not registered easily
●In the following situations, ID code registration may take longer than
usual to be completed or may not be possible.
• When the vehicle has not been
parked for approximately 15 minutes or more before being driven
• Vehicle is not driven at approximately 25 mph( 40 km / h) or more
• Vehicle is driven on unpaved roads
• Vehicle is driven near other vehicles and system cannot recognize tire pressure warning valve
and transmitters of your vehicle over those of other vehicles
• Wheel with tire pressure warning
valve and transmitter installed is inside or near the vehicle
●If the vehicle is reversed during registration, all data collected until then will be cleared. Perform driving again.
●If registration does not complete
after driving for 1 hour or more, perform the ID code registration procedure again from the beginning.
●If the tire pressure warning light
does not blink 3 times when starting ID code registration procedure, the procedure may not have
started. Perform the procedure again from the beginning.
●If the ID codes cannot be registered even when performing the above procedure, contact your SUBARU dealer.
Canceling ID code registration
To cancel ID code registration after it has been started, select“ New tire registration” again on the multimedia display.
If ID code registration has been canceled, the tire pressure warning light will turn off.
If the warning light does not turn off, ID code registration may not have been cancelled correctly. To cancel registration, select“ New tire registration” again on the multimedia display.
Selecting wheel set
Your vehicle is equipped with a tire pressure warning system with a function to register two sets of ID codes. This allows for registration of a second wheel set, for example a winter set.
• The wheel set can be changed only if a second wheel set has been registered to the system. If a second wheel set has not been registered,“ Set 2( Unregistered)” will be displayed and it will not be possible to change to the selected wheel set.
ID codes can be registered by yourself.( �P. 579)
• Only a change between both registered wheel set is possible, mixing between these wheel sets is not supported.
