7-3. Do-it-yourself maintenance
579
●Make sure to perform the tire pressure setting procedure after adjusting the tire inflation pressure. Also, make sure the tires are cold before performing the tire pressure setting procedure or adjusting the tire inflation pressure.
■ Tire inflation pressure setting procedure( Setting using the
current tire inflation pressure)
●If the power switch is turned off while setting the tire inflation pressure, the next time the power switch is turned to ON, the setting
procedure will resume and it will not be necessary to restart the procedure.
●If the tire inflation pressure setting procedure is started unnecessarily, adjust the tire inflation pressure to the specified level with the tires cold and then perform setting
by selecting a specified tire inflation pressure, or perform the tire inflation pressure setting procedure with the current tire inflation pressure.
■ If the tire inflation pressure cannot be set easily
●Normally, it takes approximately 3 minutes to complete the setting
procedure to the current tire inflation pressure.
●If the tire pressure warning light does not blink 3 times when starting the tire inflation pressure setting procedure, the procedure may not have started. Perform the procedure again from the beginning.
●If tire inflation pressure setting procedure cannot be completed after performing the above procedure, contact your SUBARU dealer.
WARNING
■ When setting using the current tire inflation pressure
Make sure to adjust the tire inflation pressure of each tire to the appropriate level before performing tire pressure setting. Otherwise, the tire pressure warning light may not illuminate even if the tire inflation pressure drops or
may illuminate even though the tire inflation pressure is normal.
Registering ID codes
■ When to register ID codes
The tire pressure warning valve and transmitter is equipped with a unique ID code. When new tire pressure warning valves and transmitters are installed, new ID codes must be registered in the tire pressure warning computer.
■ How to registration ID code
Before performing ID code registration, make sure that no wheels with tire pressure warning valve and transmitters installed are near the vehicle. 1 Park the vehicle in a safe place, turn the power switch off and wait 15 minutes or more.
2 Start the EV system.
The ID code registration procedure cannot be performed while the vehicle is moving.
3 Select on the multimedia display.
7
Maintenance and care
