5-4. Using the driving support systems
385
NOTICE
●As the target parking space will not be able to be set correctly if the surface of the parking space is on a slope or has differences
in height, the vehicle may stray from the target parking space or be slanted. Therefore, do not
use the function for this kind of parking spot.
●When parking in a narrow parking space, the vehicle may closely approach an adjacent parked vehicle. If a collision
seems likely, depress the brake pedal to stop the vehicle.
●If a detected parked vehicle is narrow or parked extremely close to the curb, the position at which assistance will park the vehicle will also be close to the curb. If it seems likely the vehicle will collide with something or drive off of the road, depress the brake pedal to stop the vehicle, and then press the Advance Park main switch to disable the system.
Leaving a parking space using the perpendicular exiting( forward / reverse) function
1 With the brake pedal depressed and P shift position selected, press the Advanced Park main switch and check that the exit direction selection screen is displayed on the multimedia display.
5
Driving
Advanced Park perpendicular exiting( forward / reverse) function
When exiting from a perpendicular parking space, if the system determines that exit is possible the perpendicular exiting( forward / reverse) function can be used. Also, depending on the surrounding environment, if it is necessary to change the direction of travel of the vehicle, the shift position can be changed by assistance control.
2 Select an arrow on the multimedia display to select the direction you wish to exit.
If the turn signal lever is operated, only exit to the left or right can be selected.
3 Depress the brake pedal and select“ Start” button.
A buzzer will sound, an operation message will be displayed on the multi-information display, and assistance will begin operating.
