342 5-4. Using the driving support systems
WARNING
●Do not damage the sensors, and always keep them clean.
●Do not attach a sticker or install a component, such as a backlit license plate( especially fluorescent type), fog lights, fender pole or wireless antenna near a radar sensor.
●Do not subject the surrounding area of the sensor to a strong impact. If subjected to an
impact, have the vehicle inspected by your SUBARU dealer. If the front or rear
bumper needs to be removed / installed or replaced, contact your SUBARU dealer.
●Do not modify, disassemble or paint the sensors.
●Do not attach a license plate cover.
●Keep your tires properly inflated.
●Do not install a suspension other than a genuine suspension.
■ Notes when washing the vehicle
●When using a high pressure washer to wash the vehicle, do not spray the sensors directly, as doing so may cause a sensor
to malfunction.
●When using steam to clean the vehicle, do not direct steam too close to the sensors, as doing so may cause a sensor to malfunction.
■ The system can be operated when
●The power switch is in ON.
●The SUBARU Parking Assist is on.
●The vehicle speed is less than about 6 mph( 10 km / h).
● Front corner sensors:
The shift position is in a position other than P.
●Front center sensors:
The shift position is in a position other than P or R.
●Rear corner and rear center sensors: The shift position is in R.
●Side sensors:( vehicles with Advanced Park)
• The vehicle is moving about 23.0
ft.( 7 m) after the EV system was started.
• The vehicle is moving about 23.0
ft.( 7 m) after the shift position was changed from R to D.
• The shift position is in R.
• switch has been pressed and
the multimedia display is displayed.
• The front or rear sensor detects a stationary object.
●Vehicles without the multimedia display or rear camera: The system will automatically turn on( enabled) and the SUBARU Parking Assist OFF indicator will turn off if the shift position is changed to R. The setting of SUBARU Parking Assist itself will not change.
■ Sensor detection information
●The sensor’ s detection areas are limited to the areas around the vehicle’ s front and rear bumpers.
