112 2-2. Charging
4 From the items displayed on the screen, press“ Edit” in the row of the charging schedule you wish to change.
• Changing registered items:
Change the desired settings as described starting from step 3 of the“ Registering the charging schedule” procedure.( �P. 110)
When a setting is changed, its icon on the calendar also changes.
• Deleting registered items: Press“ Delete”.
A deletion confirmation message will be displayed.
Press“ Delete” to delete the selected charging schedule.
When a charging schedule is deleted, its icon is also deleted from the“ Charging schedule” screen.
■ Turning“ Charge now” on 1 Display the“ Charging schedule” screen.( �P. 109)
2 Press“ Charge now”.
Each time the button is pressed,“ Charge now” switches between on and off.
After setting operations are complete, charging starts when the AC charging connector is connected.
If“ Charge now” cannot be set to on even when performing the operations above, remove the AC charging connector while the charging indicator is flashing at the normal speed and then immediately reconnect it.
If this operation is performed, the setting of charging current and the upper limit of the electric current will be temporarily initialized.( �P. 97)
■ Displaying next event Turn the power switch off.
Next event will be displayed according to the charging schedule
settings. *
*: If the multimedia customize content“ ACC customize” is not set to OFF, the ending screen will not be displayed. If it is this case, check the settings of the multimedia.
When press“ OK”, close Next charging event screen.
When press“ Charge now”, charge now is turned on.
