2-2. Charging
107
Registering the charging schedule
The charging schedule can be registered on the multimedia.
Only“ Charge Now” can be set on the multi-information display.
• Multi-information display operation: �P. 108
• Multimedia operation: �P. 109
■ Charging schedule function
●The charging schedule cannot be set while driving.
●A maximum of 15 charging schedules can be registered.
If the charging mode is set to“ Start and stop” and the start time and end
time are set to the same time, charging will be performed for 24 hours from the start time.
The charging schedule function can not be used when using DC
charging.
■ To make sure that the charging schedule function operates correctly
Check the following items. ●Adjust the clock to the correct time For details, refer to the“ MULTIME- DIA OWNER’ S MANUAL”.
●The day of the week is set correctly
For details, refer to the“ MULTIME- DIA OWNER’ S MANUAL”.
●Check that the power switch is turned off
●After registering the charging schedule, connect the AC
charging connector
The charging start time is determined based on the charging schedule at the time that the AC charging connector was connected.
● Connect the AC charging connector before the start time
When the charging mode is set to“ Start”, if you connect the AC charging connector after the set start time, the next charging schedule will be referenced.
When the charging mode is“ Start and stop”, if you connect the AC charging connector after the start time, charging will start immediately and charging will be performed until the stop time.
●After connecting the AC charging
connector, check that the charging indicator of the charging port flashes( �P. 85)
●Do not use an outlet that has a power cut off function( including a
charging schedule function)
Use an outlet that constantly supplies electricity. For outlets where the power is cut off due to a charging schedule function, etc., charging may not be carried out according to plan if the power is cut off during the set time.
2
Electric Vehicle system
