274
BSD / RCTA( If Equipped)- When both your vehicle and a vehicle driving on a neighboring lane are driving on the far side of each lane.- When several narrowly-spaced vehicles are approaching in a row- In low radius bends( tight bends or when making turns at an intersection)- When there is a difference in height between your lane and the neighboring lane- Immediately after the BSD / RCTA is activated by touching“ BSD / RCTA”- Immediately after the shift lever / select lever is shifted to the“ R” position- When extremely heavy cargo is loaded in the trunk � During reversing, operation of the BSD / RCTA approach indicator light and the warning buzzer may be delayed or the system may fail to issue these warnings under the following conditions.
- When backing out of an angled parking space- When a large-sized vehicle is parked next to your vehicle( That vehicle prevents the propagation of radar waves.)- When reversing on sloped roads- When reversing at a high speed
702802 � The BSD / RCTA approach indicator light may illuminate when driving close to solid objects on the road or road side( such as guardrails, tunnels and sidewalls).
� When turning at an intersection in urban areas, or a multilane intersection, the BSD / RCTA approach indicator light may flash.
� If a building or a wall exists in the reversing direction, the BSD / RCTA approach indicator light may flash and the warning buzzer may sound.
� In the following cases, the system may detect a vehicle driving two lanes away from your vehicle.
- When your vehicle drives on the near side of its lane from the corresponding vehicle
