204
Manual Climate Control
Heat-def: Windshield defroster outlets, foot outlets and both side outlets of the instrument panel 403489
Heat: Foot outlets, both side outlets of the instrument panel and some through windshield defroster outlets( A small amount of air flows to the windshield and both side windows to prevent fogging.)
403490
■ Temperature Control
Turn the temperature control dial to set the preferred interior temperature. NOTE
The controllable temperature range may vary depending on the regional specifications of the vehicle. ▼ MAX A / C mode
For quicker cooling, press the MAX A / C button.
When the MAX A / C mode is on, the following settings will be changed automatically.
� The air conditioner will turn on.
� The temperature will be set on the lowest.
� The fan speed will be set on the maximum speed.
� The air inlet will be set to the recirculation mode.
� The airflow mode setting will be set to the ventilation mode.
To turn off MAX A / C mode and return the previous setting, press the MAX A / C button again.
